-9-

4.

Connecting of the Cable

Indoor Unit

Connect the power connecting cord to the indoor unit
by connecting the wires to the terminals on the control
board individually in accordance with the outdoor unit
connection.

Note: For some models, it is necessary to remove the cabinet to
connect to indoor unit terminal.

Outdoor Unit

1). Remove the access door from the unit by loosening
the screw. Connect the wires to the terminals on the
control board individually as the following.

2). Secure the power connecting cord onto the control
board with cable clamp.

3). Reinstall the access door to the original position
with the screw.

4) Use a recognized circuit breaker for 7kW model or
above between the power source and the unit.

A disconnecting device to adequately disconnected all
supply lines must be fitted.

Caution:

1. Never fail to have an individual power circuit specifically for the air conditioner. As for the method of
wiring, refer to the circuit diagram posted on the inside of the access door.

2. Confirm that the cable thickness is as specified in the power source specification.

3.Check the wires and make sure that they are all tightly fastened after cable connection.

4. Be sure to install an earth leakage circuit breaker in wet or moist area.

Cable Specifications

Capacity

(kW )

Power  cord

Power connecting cord

Power connecting cord1

Main
power
supply

Type

Normal cross

- sectional area

Type

Normal cross

- sectional area

Type

Normal cross

- sectional area

1,5 ~ 3,8

H05VV-F

0.75~1.5mm

2

X3

H07RN-F
H05RN-F

1.5mm

2

X3

0.75~1.0mm

2

X3

H05RN-F

0.75mm

2

X2

(Heat-pump)

To indoor

4,1 ~ 7

H05VV-F

1.5~2.5mm

2

X3

H07RN-F

1.5~2.5mm

2

X3

H05RN-F

0.75mm

2

X2

(Heat-pump)

To indoor

5,3 ~ 8,8

H05VV-F

1.5~2.5mm

2

X3

H07RN-F

1.5~2.5mm

2

X4

H05RN-F

0.75mm

2

X2

(Heat-pump&Optional)

To indoor

5,3 ~ 8,8

H07RN-F

2.5mm

2

X3

H05RN-F

H07RN-F

1.0mm

2

X3

1.0mm

2

X4Cooling only

H05RN-F

0.75mm

2

X3

(Heat-pump)

To outdoor

7 ~ 10,6

H07RN-F

2.5~4.0mm

2

X3

H05RN-F

H07RN-F

0.75mm

2

X4

1.0mm

2

X4

H05RN-F

0.75mm

2

X2

(Heat-pump&Optional)

To outdoor

7 ~ 10,6

H07RN-F

1.5mm

2

X5

H05RN-F

0.75mm

2

X4

H05RN-F

0.75mm

2

X2

(Heat-pump)

To outdoor

The cord may be different from the list above. It may be used as the next list. And it can be larger.

0-6A, use 0.75mm

2

or 18AWG. 0-10A, use 1mm

2

or 16AWG. 0-16A, use 1.5mm

2

or 14AWG.

0-20A, use 2.5mm

2

or 14AWG. 0-25A, use 2.5mm

2

or 12AWG. 0-32A, use 4mm

2

.

Front
panel

Terminal
(inside)

Cabine
t

Indoor
unit

Chassi
s

Access door
Terminal(ins
ide)

Outdoor unit

The figures in this manual are based on the
external view of a standard model.
Consequently, the shape may differ from that of
the air conditioner you have selected.
