EN

Installation

FreshJet

14

Electrical connection

The complete circuit diagram can be found in fig.

i

:

Keys for fig.

j

:

See fig.

d

230 V

w

cable

➤

Connect the roof air conditioner with the 230 V

w

voltage supply.

Connect the cables (

1

) to a cable connector (

2

).

Remote light switch (not included in the scope of delivery)

You can connect the lighting to a remote light switch. This enables you to switch on
the lighting remotely.

To do this, proceed as follows:

➤

Disconnect the 2-pin plug (

3

) from the socket on the circuit board of the air outlet

unit.

Item

Description

1

230 V

w

 mains

2

Compressor

3

Fan condenser

4

Fan condenser (FreshJet 3200 only)

5

Fan evaporator

6

Battery

7

Remote socket

8

Temperature sensor

9

Heating (FreshJet 1700, 2000, 2200 only)

10

Heat Pump (FreshJet 3200 only)

11

Soft Start (FreshJet 2000, 2200, 3200 only)

Item

Description

1

Remote light switch

2

Circuit board in the air outlet unit
