EN

FreshJet

Installation

11

•

Make sure that the grounding cable of the air conditioner is connected to the
vehicle‘s grounding system.

There are two ways of installing the roof air conditioner:

•

Making a new opening (chapter “Making a new opening” on page 11). In this
case the opening must be reinforced by an appropriate frame.

•

Using the existing roof hatch openings (ventilation hatch) in the vehicle (chapter
“Installing in a roof hatch opening already provided” on page 11).

8.2

Making a new opening

See fig.

3

➤

Select an area at the centre on the roof between two longitudinal supports.

➤

Mark the position and size of the opening using the template included in the
packaging (

A

 and

B

).

See fig.

4

➤

Drill out the corners (

A

).

➤

Carefully cut out the opening on the roof using a keyhole saw or a similar tool (

B

).

Make sure no electrical power cables are damaged.

See fig.

5

➤

Before installation, check whether the roof hole needs reinforcing.

➤

Remove the foam according to the width of your reinforcing rails (not in scope of
delivery) (

A

).

➤

Fit the reinforcing rails (

B

).

8.3

Installing in a roof hatch opening already provided

I

NOTE

•

Existing roof hatch openings in accordance with fig.

3

 are suitable

for installing the roof air conditioner.

•

Dispose of all waste material, glue, silicone and seals separately.
Observe the disposal guidelines.

•

The manufacturer only assumes liability for parts included in the
scope of delivery. The validity of the warranty expires if the device is
installed together with third-party parts.
