EN

FreshJet

Installation

13

8.5

Installing the roof air conditioner with Chillout ADB

A

See fig.

0

➤

Lift the roof air conditioner onto the roof of the vehicle.

➤

Position the roof air conditioner over the installation opening.

Observe the direction of travel.

Attaching the roof air conditioner

See fig.

a

➤

Position the roof air conditioner into the mounting opening using the conical
noses.

See fig.

b

➤

Choose the suitable seal in accordance with the following table:

➤

Position the seal with the adhesive side on the ADB.

➤

Fasten the mounting frame (

3

) on the underside of the roof air conditioner with

the 4 screws supplied.

See fig.

c

A

➤

Tighten the screws using a torque spanner and a fastening torque of 2.5 Nm.

NOTICE! Damage hazard

Observe the structural strength of the roof of the vehicle. The roof of the
vehicle must be able to bear the weight of the roof air conditioner. The
roof must not be indented or deformed by the weight of the unit, even
over a longer period of time.

Roof thickness

Seal thickness

25 – 30 mm

15 mm

30 – 40 mm

30 mm

40 – 60 mm

45 mm

NOTICE! Damage hazard

Tighten to the specified torque.
