EKHTS260AC6W1

Domestic hot water tank for air to water heat pump system

4PW73828-1 – 2012.05

Installation manual

1

C

ONTENTS

Page

Introduction ........................................................................................ 1

General information ..................................................................... 1
Scope of this manual................................................................... 1
Model identification ..................................................................... 1

Accessories ....................................................................................... 1

Accessories supplied with the domestic hot water tank ............. 1
Optional equipment ..................................................................... 1

Overview of the unit ........................................................................... 2

Position of flexibles ...................................................................... 2
Main components ........................................................................ 2
Safety devices ............................................................................. 3
Outlook diagram .......................................................................... 3

Installation of the EKHTS domestic hot water tank ........................... 3

Installation guidelines .................................................................. 3
Installing and commissioning the domestic hot water tank ......... 4

Maintenance ...................................................................................... 7

Descaling .................................................................................... 7
Draining ....................................................................................... 8

Troubleshooting ................................................................................. 8

General guidelines ...................................................................... 8
General symptoms ...................................................................... 8

Disposal requirements ....................................................................... 8

Technical specifications ..................................................................... 8

Domestic hot water tank specifications ....................................... 8

The English text is the original instruction. Other languages are
translations of the original instructions.

I

NTRODUCTION

General information

Thank you for purchasing this domestic hot water tank.

The domestic hot water tank must be installed by a licensed
technician and be installed in compliance with instructions as of
subject in this manual, all current legislation, codes of practice and
regulations governing the installation of unvented hot water cylinders
in force at the date of installation.

The EKHTS domestic hot water tank can be connected to EKHBRD*
units. The domestic hot water tank is available in one size:
approximately 260 litre. The domestic hot water tank can be mounted
on top of the indoor unit. For installation of the domestic hot water
tank on the floor next to the indoor unit, the dedicated EKFMAHTB
connection kit is required.

In case of EKHBRD*AA* units, the kit EKMKHT1 is required.

Scope of this manual

This installation manual describes the procedures for installing and
connecting the EKHTS domestic hot water tank.

Model identification

Domestic hot water tank

A

CCESSORIES

Accessories supplied with the domestic hot water tank

See figure 1.

Optional equipment

■

EKFMAHTB

Connection kit for installation of the domestic hot water tank on
the floor next to the indoor unit.

Refer to the installation manual of the kit for more details.

■

EKMKHT1

In case the EKHTS*AC domestic hot water tank is to be installed
on top of an EKHBRD*AA* series indoor unit, the additional
EKMKHT1 kit is required.

Refer to the instruction sheet of the kit for more details.

EKHTS260AC6W1

Domestic hot water tank

for air to water heat pump system

Installation manual

READ THESE INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION. KEEP THIS MANUAL IN A HANDY
PLACE FOR FUTURE REFERENCE.

PLEASE LEAVE THIS MANUAL WITH THE EKHTS
DOMESTIC HOT WATER TANK AFTER INSTALLATION.

IMPROPER INSTALLATION OR ATTACHMENT OF
EQUIPMENT OR ACCESSORIES COULD RESULT IN
ELECTRIC SHOCK, SHORT-CIRCUIT, LEAKS, FIRE OR
OTHER DAMAGE TO THE EQUIPMENT. BE SURE ONLY
TO  USE ACCESSORIES MADE BY DAIKIN WHICH ARE
SPECIFICALLY DESIGNED FOR USE WITH THE
EQUIPMENT AND HAVE THEM INSTALLED BY A
PROFESSIONAL.

IF UNSURE OF INSTALLATION PROCEDURES OR USE,
ALWAYS CONTACT YOUR DAIKIN DEALER FOR
ADVICE AND INFORMATION.

THE UNIT DESCRIBED IN THIS MANUAL IS DESIGNED
FOR INDOOR INSTALLATION ONLY AND FOR AMBIENT
TEMPERATURES RANGING 5°C~30°C.

EK

HTS

260

AC

6

W1

Power supply (3~, 400 V, 50 Hz)

Power of heater

Series

Identification of type

Hot water Tank Stainless steel

European Kit

1

Clamp

2

Knock-out hole assembly (grommet + tie-wraps + screws)

3

Installation manual

4

Unpacking instruction sheet

5

3-way valve assembly (body + motor + clamps) + T-piece
