The  appliance  can  be  inserted  into  a  row  of  kitchen  units.  To

match the appliance

 Fig. 13 (2) to the height of the row of units,

a  suitable  stack  cabinet

  Fig.  13  (1)  can  be  fitted  above  the

appliance.
When  inserting  the  appliance  into  a  row  of  kitchen  units  (max.

depth  580  mm ),  the  appliance  can  be  installed  directly  next  to

the kitchen unit

 Fig. 13 (3). The appliance door projects relative

to  the  front  of  the  kitchen  unit  by  34  mm   at  the  side  and  by

50  mm  in  the  middle  of  the  appliance.  It  can  be  opened  and

closed perfectly as a result.
Important for the ventilation:

-

At the back of the stack cabinet there has to be a ventilation

duct  of  at  least  50  mm  depth  throughout  the  width  of  the

stack cabinet.

-

The  ventilation  space  under  the  ceiling  has  to  be  at  least

300 cm

2

.

If  the  appliance  is  installed  with  the  hinges  next  to  a  wall

Fig. 13 (4), the distance between appliance and wall has to be

at  least  40  mm .  This  corresponds  to  the  projection  of  the

handle when the door is open.

4.5 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

expanded polystyrene parts

-

polythene bags and sheets

-

polypropylene straps

-

nailed wooden frame with polyethylene panel*

u

Take the packaging material to an official collecting point.

4.6 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The  type  of  current  (alternating  current)  and  voltage  at  the

installation site have to conform with the data on the type plate

(see Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.
It must be easily accessible so that the appliance can

be quickly disconnected from the supply in an emer-

gency.

u

Check the electrical connection.

u

Plug in the power plug.

4.7 Switching on the appliance

Note

u

To  switch  on  the  entire  appliance  it  is  necessary  only  to

switch on the freezer compartment.

Put  the  appliance  into  operation  about  2  hours  before  first

loading food to be frozen.
Do  not  load  food  to  be  frozen  before  the  temperature  display

reads -18 °C.

4.7.1 Switching on the freezer compartment

u

Press On/Off button, freezer compartment

 Fig. 3 (6).

w

The  temperature  display  of  the  refrigerator  compartment

indicates the current temperature inside.

w

The temperature display of the freezer compartment and the

alarm symbol flash until the temperature is sufficiently low. If

the  temperature  is  above  0  °C,  dashes  flash.  If  it  is  below,

the current temperature flashes.

4.7.2 Switching on refrigerator and BioFresh

compartment

u

Press On/Off button, refrigerator compartment

 Fig. 3 (1).

5 Control

5.1 Brightness of the temperature

display

You can adjust the brightness of the temperature display to the

light conditions of the room in which the appliance is installed.

5.1.1 Adjusting the brightness

The  brightness  is  adjustable  between

h0

  (no  illumination)  and

h5

 (maximum luminosity).

u

To  activate  the  setting  mode:  press  the  SuperFrost  button

Fig. 3 (4) for about 5 s.

w

The display indicates

c

.

w

The menu symbol

 Fig. 3 (17) shines.

u

Using the Up setting button, freezer compartment

 Fig. 3 (11)

or  Down  setting  button,  freezer  compartment

  Fig.  3  (9),

select

h

.

u

To confirm: briefly press the SuperFrost button

 Fig. 3 (4).

u

To  make  the  display  brighter:  press

Up  button,  freezer  compartment

Fig. 3 (11).

u

To  make  the  display  darker:  press

Down  button,  freezer  compartment

Fig. 3 (9).

u

To  confirm:  press  SuperFrost  button

Fig. 3 (4).

w

The brightness is adjusted to the new value.

u

To deactivate the set-up mode: press On/Off button, freezer

compartment

 Fig. 3 (6).

-or-

u

Wait for 5 minutes.

w

The  temperature  is  indicated  again  in  the  temperature

display.

5.2 Child proofing

The  child-proofing  function  enables  you  to  make  sure  that  the

appliance is not inadvertently switched off by playing children.

5.2.1 Setting the child lock function

u

To  activate  the  setting  mode:  press  SuperFrost  button

Fig. 3 (4) for about 5 s.

w

The display indicates

c

.

w

The menu symbol

 Fig. 3 (17) shines.

u

Briefly press the SuperFrost button

 Fig. 3 (4).to confirm.
