6.3 Cleaning the IceMaker

The drawer of the IceMaker has to be emptied and slid in.

u

To  activate  the  setting  mode:  press  the  SuperFrost  button

Fig. 3 (4) for about 5 s.

w

The display indicates

c

.

w

The menu symbol

 Fig. 3 (17) shines.

u

Using  the  Up  setting  button,  freezer  compartment

Fig.  3  (11)/  Down  setting  button,  freezer  compartment

Fig. 3 (9) select

I

.

u

To confirm: press the SuperFrost button

 Fig. 3 (4).

u

Using  the  Up  setting  button,  freezer

compartment

  Fig.  3  (11)/  Down

setting  button,  freezer  compartment

Fig. 3 (9) select

Ic

.

u

To  confirm:  press  the  SuperFrost

button

 Fig. 3 (4).

w

The IceMaker moves into the cleaning position and switches

off.

u

To  deactivate  the  setting  mode:  press  the  On/Off  button,

freezer compartment

 Fig. 3 (6).

-or-

u

Wait for 2 minutes.

w

The  temperature  is  indicated  again  in  the  temperature

display.

u

Remove the drawer.

u

Clean  the  ice  cube  tray  and  drawer  with  warm  water.  If

necessary, use mild washing-up liquid. Then rinse.

u

Slide in the drawer again.

If washing-up liquid was used:

u

throw away the first three loads of ice cubes to get rid of any

remaining washing-up liquid.

Either leave the IceMaker switched off in this position or switch

the IceMaker on again (see 5.7.9) .

6.4 Changing the interior light with bulb

Bulb data

T25 tube, Philips

max. 25 W

Fitting: E14

Type of current and voltage must conform with the details on

the type plate

Fig. 20

u

Switch off the appliance.

u

Pull out the power plug or switch off the fuse.

u

To  remove  the  cover

  Fig.  20  (1):  put  your  finger  behind  the

cover and disengage it.

u

Pull out the glass shelf

 Fig. 20 (2).

u

Change the bulb

 Fig. 20 (3).

u

Slide the glass shelf back in.

u

Attach  the  cover  again,  engage  it  at  the  right  and  left  and

pay attention that the middle hook

 Fig. 20 (4) grips over the

glass shelf.

6.5 Customer service

First  check  whether  you  can  correct  the  fault  yourself  by  refer-

ence to the list (see Malfunction). If this is not the case, please

contact  the  customer  service  whose  address  is  given  in  the

enclosed customer service list.

WARNING

Risk of injury if repair work is not carried out professionally!

u

Have  any  repairs  and  action  -  not  expressly  specified  -  on

the  appliance  and  mains  cable  carried  out  by  service

personnel only. (see Maintenance)

u

Read  the  appliance

designation

Fig.  21  (1),  service

No.

  Fig.  21  (2)  and

serial  No.

  Fig.  21  (3)

off  the  type  plate

located  inside  the

appliance  on  the  left-

hand side.

Fig. 21

u

Notify  the  customer  service,  specifying  the  fault,  appliance

designation

 Fig. 21 (1), service No. Fig. 21 (2) and serial No.

Fig. 21 (3).

w

This will help us to provide you with a faster and more accu-

rate service.

u

Keep  the  appliance  closed  until  the  customer  service

arrives.

w

The food will stay cool longer.

u

Pull out the mains plug (not by pulling the connecting cable)

or switch off the fuse.

7 Malfunction

Your  appliance  is  designed  and  manufactured  for  a  long  life

span  and  reliable  operation.  If  a  malfunction  nonetheless

occurs  during  operation,  check  whether  it  is  due  to  a  handling

error.  In  this  case  you  will  have  to  be  charged  for  the  costs

incurred,  even  during  the  warranty  period.  You  may  be  able  to

rectify the following faults yourself:
Appliance does not work.

→

The appliance is not switched on.

u

Switch on the appliance.

→

The power plug is not properly inserted in the wall socket.

u

Check power plug.

→

The fuse of the wall socket is not in order.

u

Check fuse.

The compressor runs for a long time.

→

The compressor switches to a low speed when little cold is

needed. Although the running time is increased as a result,

energy is saved.

u

This is normal in energy-saving models.

→

SuperFrost is activated.

u

The  compressor  runs  for  longer  in  order  to  rapidly  cool  the

food. This is normal.

→

SuperCool is activated.

u

The  compressor  runs  for  longer  in  order  to  rapidly  cool  the

food. This is normal.

Excessive noise.

→

Speed-controlled*  compressors  may  produce  varying

running noise due to different speed steps.

u

The sound is normal.

Malfunction

15
