5.7.8 Cold storage accumulators

The  cold  storage  accumulators  prevent  the  temperature  from

rising too fast in the event of power failure.
Using cold storage accumulators

u

Place the cold storage accumula-

tors  in  the  top  freezer  compart-

ment to save space.

u

Place  the  frozen  cold  storage

accumulators  on  the  frozen  food

in  the  upper  front  area  of  the

freezer compartment.

5.7.9 IceMaker

The  IceMaker  and  the  water  reservoir  situated  in  the  refriger-

ator  compartment  can  be  used  to  produce  ice  cubes  or  to

provide chilled drinking water.
The  IceMaker  is  in  the  top  drawer  of  the  freezer  compartment.

The drawer is marked "IceMaker".
Make certain that the following conditions are met:

-

The appliance is level.

-

The appliance is connected.

-

The freezer compartment is switched on.

-

The water tank was cleaned with water and is filled.

Filling the water tank

WARNING

Risk of poisoning!

u

The water quality has to comply with the drinking water ordi-

nance of the respective country (e.g. 98/8

u

The  IceMaker  serves  exclusively  for  making  ice  cubes  in

household quantities and has to be operated with water suit-

able for the purpose.

NOTICE

Risk of damage to the IceMaker!

Liquids  containing  sugar,  such  as  soft  drinks,  fruit  juices  or

similar,  gum  up  the  pump  and  therefore  lead  to  total  pump

failure and, as a consequence, to damage to the IceMaker.

u

Fill  the  water  reservoir  with  drinking  water  only!  Do  not  use

any liquids containing sugar, such as soft drinks, fruit juices

or similar!

The  IceMaker  is  supplied  with  water  from  a  water  tank  in  the

refrigerator compartment (see Appliance at a glance).
When  the  water  tank  is  empty,  the  water  tank  symbol
Fig. 3 (20) shines.

Before initial operation:

u

clean  the  water  tank  thoroughly  with  water  to  remove  any

dust etc.

u

Pull the water tank forwards.

u

Open the front flap and fill the

tank with water.

u

Place  the  filled  water  tank  in

the  holder  and  slide  it  all  the

way back.

Note

u

The water reservoir has to be slid all the way into the bracket

provided for the purpose in the refrigerator compartment!

Switching on the IceMaker

Fig. 19

u

Pull out the drawer.

u

Press  the  On/Off  button

  Fig.  19  (1)  so  that  the  LED

Fig. 19 (2) shines.

u

Push in the drawer.

w

The IceMaker symbol

 Fig. 3 (21) shines.

Note

u

The  IceMaker  produces  ice  cubes  only  if  the  drawer  is  fully

closed.

Setting the water intake time
The opening time of the IceMaker valve can be set to affect the

size of the ice cubes produced.
The  water  intake  time  is  adjustable  in  steps  from

E1

  (short

intake time) to

E8

 (long intake time).

u

To  activate  the  setting  mode:  press  the  SuperFrost  button

Fig. 3 (4) for about 5 s.

w

The display indicates

c

.

w

Themenu symbol

 Fig. 3 (17) shines.

u

Using the Up setting button, freezer compartment

 Fig. 3 (11)

and  Down  setting  button,  freezer  compartment

  Fig.  3  (9)

select

E

.

u

To confirm: briefly press the SuperFrost button

 Fig. 3 (4).

u

To  increase  the  water  intake  time:

press  the  Up  setting  button,  freezer

compartment

 Fig. 3 (11).

u

To  reduce  the  water  intake  time:

press  the  Down  setting  button,

freezer compartment

 Fig. 3 (9).

u

To  confirm:  press  the  SuperFrost

button

 Fig. 3 (4).

u

To  deactivate  the  setting  mode:  press  the  On/Off  button,

freezer compartment

 Fig. 3 (6).

-or-

u

Wait for 2 minutes.

w

The  temperature  is  indicated  again  in  the  temperature

display.

Producing ice cubes
The  production  capacity  depends  on  the  freezer  temperature.

The  lower  the  temperature,  the  more  ice  cubes  can  be

produced in a specific period.
The ice cubes drop from the IceMaker into the drawer. When a

certain  filling  level  has  been  reached,  no  further  ice  cubes  are

produced. The IceMaker does not fill the drawer right up to the

brim.

Control

13
