English

ATTENTION!

The refrigerator must be

disconnected from power supply

during the re-hanging of the door.

Please note that when removing

the doors, excessive force is not

required, as well as exposure to the

walls of refrigerator with sharp and

cutting objects.
For the subsequent correct

installation of the door make

sure that it opens freely and its

movement is not hindered by

foreign objects, such as furniture or

household appliances located in the

immediate vicinity.

If necessary, you can change the sides

of the door opening from the right one

(according to the delivery set) to the left

one.
The scheme of doors re-hanging:
1.  Unscrew and remove the plastic cover

from the upper door hinge.

2.  Unscrew the bolts of the upper hinge

and remove it.

Re-hanging of doors

3.  Unscrew the bolts of the mounting

plate of the top cover.

4.  Remove the refrigerator door and put

it aside.

5.

Remove the central hinge by first

unscrewing the screws.

6.  Remove the freezer door and put it

aside.

7.  Pull the plug out of the hinge hole

located on one side of the freezer

door and insert this plug into the

hole on the other side of the door.

8.  Remove the refrigerator legs.
9.  After unscrewing the bolts, remove

the lower hinge. Flip the lower hinge

and place it on the other side of the

refrigerator.

10. Swap the adjustable legs and install

them. Set the refrigerator by level.

11. Move the central hinge to the other

side after the lower door has been

installed.

12. Install the upper hinge, the upper

hinge cover and the upper mounting

plate after installing the upper door.
