 7

Step 3: Generator Start up   Figure

1

Disconnect all electrical loads from the generator. Use

the following start instructions:

  1.  Make sure unit is outdoors on a level surface.

NOTICE

 Failure to operate the unit on a level surface

may cause the unit to shut down.

  2.  Rotate fuel valve (

R

) to ON (I) position.

  3.  Move choke lever (

P

) to CHOKE ( ) position.

NOTICE

 For a warm engine, be sure choke lever is in

RUN ( ) position.

  4.  Turn and hold key in start switch (

B

) to START

( )

position until generator starts. DO NOT hold key in

START

( )

 position for more than 5 seconds. Pause

for at least 30 seconds between starting attempts.

NOTICE

 If battery is discharged, turn key in start switch

to RUN (I) position, grasp recoil handle and pull slowly

until slight resistance is felt. Then pull rapidly one time

only to start engine.

  5.  As engine warms up, slowly move choke lever to

RUN ( ) position.

NOTICE

 This unit is equipped with a low oil protection

device. Oil must be at proper level for engine to run. If

the engine oil drops below a preset level, an oil switch

will stop the engine. Check oil level with dipstick.

WARNING!

   Exhaust heat / gases could

ignite combustibles, structures or

damage fuel tank causing a fire, resulting

in death or serious injury. Contact with muffler area could

cause burns resulting in serious injury. Pay attention to

the warnings on the generator. Do not touch hot parts

and avoid hot exhaust gases.

Step 4: Connecting Electrical Loads   Figure

1

Generator may only be loaded up to rated power under

the rated conditions as shown on unit data tag. Reduce

load when using generator outside of rated conditions.

Use only high quality, well-insulated extension cables in

accordance with IEC 245-4 with the generator’s 230 Volt

AC outlets. Inspect extension cables before each use.

Check that all extension cables are suitably rated and

are not damaged. When using extension cords under 40°

C, the total length of cords for a cross section of 1.5 mm²

should not exceed 50 m or for a cross section of 2.5 mm²

should not exceed 80 m.

WARNING!

  Damaged or overloaded extension

cords could overheat, arc, and burn resulting in

death or serious injury. Electrical equipment,

including cables and plug connections, should not be

defective.

NOTICE

 Connect electrical loads in off position then

turn on for operation.

230 Volt AC Receptacle

Use receptacles (

E

 or

F

) to operate 230 Volt AC, single-

phase, 50 Hz electrical loads. The 16A receptacles

are protected against overload by push-to-reset circuit

breakers (

G

). The 32A receptacle is protected against

overload by the main breaker (

C

). If the main breaker

trips, it cuts power to all receptacles.

Protection of electrical components depends on circuit

breakers specifically matched to the generator. Replace

circuit breaker with identical rating and performance

characteristics.

WARNING!

  Generator voltage could cause

electrical shock or burn resulting in death or

serious injury. Do not touch bare wires or

receptacles. Do not use generator with electrical cords

which are worn, frayed, bare or otherwise damaged. Do

not operate generator in the rain or wet weather. Do not

handle generator or electrical cords while standing in

water, while barefoot, or while hands or feet are wet. Do

not allow unqualified persons or children to operate or

service generator. Keep children a safe distance from

generator.

Step 5: Generator Shut Down

  1.  Turn off and unplug all electrical loads from generator

panel receptacles. Never  stop engine with electrical

devices plugged in and turned on.

  2.  Let engine run at no-load for one minute to stabilize

internal temperatures of engine and generator.

  3.  Turn key in start switch to OFF (0) position.

  4.  Rotate fuel valve to OFF (0) position.
