14

WARNING:

Periodically inspect the blade

adapter for cracks, especially if you strike a foreign object.
Replace when necessary.
For best results your blade should be sharp. The blade
may be resharpened by removing it and either grinding or
filing the cutting edge keeping as close to the original
bevel as possible. It is extremely important that each
cutting edge receives an equal amount of grinding to
prevent an unbalanced blade. Improper blade balance will
result in excessive vibration causing eventual damage to
the engine and mower. Be sure to carefully balance blade
after sharpening. The blade can be tested for balance by
balancing it on a round shaft screwdriver. Remove metal
from the heavy side until it balances evenly.

(Fig. 26)

Before reassembling the blade and the blade adapter to
the unit, lubricate the engine crankshaft and the inner
surface of the blade adapter with light oil. Install the blade
adapter on the crankshaft. Refer to

Fig. 26

. Place the

blade with the part number facing away from the adapter.
Align the washer over the blade and insert the hex bolt.
Tighten the hex bolt to the torque listed below.

10-3 BLADE MOUNTING TORQUE

Center Bolt must be tightened to 35 - 45 Nm torque. To
insure safe operation of your unit. ALL nuts and bolts
must be checked periodically for correct tightness. After
prolonged use, especially in sandy soil conditions, the
blade will become worn and lose some of the original
shape. Cutting efficiency will be reduced and the blade
should be replaced.
Replace with an approved factory replacement blade only.
Possible damage resulting from blade unbalance
condition is not the responsibility of the manufacturer.
When you change the blade, must use the original type
marked on the blade (MAKITA 263001433 for PLM4120N;
MAKITA 263001451 for PLM4620N2) (for order the blade,
contact your local dealer or call our company).

WARNING:

Do not touch rotating blade.

10-4 ENGINE

Refer to the separate engine manual for engine
maintenance instructions.
Maintain engine oil as instructed in the separate engine
manual packed with your unit.
Read and follow instructions carefully.
Service air cleaner as per separate engine manual under
normal conditions. Clean every few hours under extremely
dusty conditions. Poor engine performance and flooding
usually indicates that the air cleaner should be serviced.
To service the air cleaner, refer to the separate engine
manual packed with your unit.
The spark plug should be cleaned and the gap reset once
a season. Spark plug replacement is recommended at the
start of each mowing season; check engine manual for
correct plug type and gap specifications.
Clean the engine regularly with a cloth or brush. Keep the
cooling system (blower housing area) clean to permit
proper air circulation which is essential to engine
performance and life. Be certain to remove all grass, dirt
and combustible debris from muffler area.

11. STORAGE INSTRUCTIONS

(OFF SEASON)

The following steps should be taken to prepare lawn
mower for storage.
1. Empty the tank after the last mowing of the season.

a) Empty the petrol tank with a suction pump.

CAUTION:

 Do not drain the petrol in closed

rooms, in close proximity of open fire, etc. Do not smoke!
Petrol fumes can cause explosion or fire.

b) Start the engine and let it run until it has used up all

remaining petrol and stalls.

c) Remove the spark plug. Use an oilcan to fill

approx. 20 ml oil into the combustion chamber.
Operate the starter to evenly distribute the oil in the
combustion chamber. Replace the spark plug.

2. Clean and grease the lawn mower carefully as

described above under “LUBRICATION
INSTRUCIONS”.

3. Slightly grease the cutter to avoid corrosion.
4. Store the lawn mower in a dry, clean and frost-

protected place, out of reach of unauthorized persons.

CAUTION:

 The engine must have completely

cooled down before storing the lawn mower.

NOTE:

When storing any type of power equipment in an
unventilated or material storage shed;
- Care should be taken to rust-proof the equipment.

Using a light oil or silicone, coat the equipment,
especially cables and all moving parts.

- Be careful not to bend or kink cables.
- If the starter rope becomes disconnected from rope

guide on handle, disconnect and ground the spark plug
wire, depress the blade control handle and pull the
starter rope out from engine slowly. Slip the starter rope
into the rope guide bolt on handle.

Transport

Turn the engine off and allow the engine to cool down.
Then disconnect the spark plug wire and empty the fuel
tank according to the instructions in the engine manual.
Ensure not to bend or damage the cutter when pushing
the lawn mower over obstacles.
