8

GB

up with a switch (9) connected to the plug, which are

fi

 xed in the upper part of the handle. A hanger (10) and

clamps are used to safeguard the cables. The movable
part of the lawnmower is composed of rear (11) and front
(12) wheels fastened by screw axles.

2. SAFETY INSTRUCTIONS

Explanation of symbols
In this manual and/or on the machine the following
symbols are used:

In accordance with essential applicable safety
standards of European directives

Class II machine - Double insulation

Risk of damaging material and/or physical in-
juries

Remove plug from the mains immediately if
cable is damaged or cut

Read instruction manual

Keep

fl

 exible cord away from the cutting

blades

Blades continue to rotate after switching off
machine/do not touch rotating blade!

Outdoor noise

Electricity

•  We strongly recommend the use of a Residual Cur-

rent Device (RCD) of not more than 30 mA, at the
plug socket when using this appliance.

•  All electrical connections e.g. extension cable, must

be of an approved waterproof type for outdoor use
and marked accordingly. Extension cables must be
threecore, one of which is EARTH.

Persons

•  Never allow children or people unfamiliar with these

instructions to use the appliance. Local regulations
may restrict the age of the operator.

•  Never mow while people, especially children, or pets

are nearby.

•  The operator or user is responsible for accidents or

hazards occurring to other people or their property.
Preparation

•  While mowing, always wear substantial footwear

and long trousers.

•  Do not operate the appliance when barefoot or

wearing open sandals.

•  Thoroughly inspect the area where the appliance

is to be used and remove all stones, sticks, wires,
bones, and other foreign objects.

ELECTRIC LAWNMOWER

SAFETY AND OPERATING INSTRUCTIONS

For your own safety and for the safety of others, please
read these instructions carefully before using this ap-
pliance.

WARNING!

 Always read the instruction for

electrical products carefully before use. It will
help you understand your product more eas-

ily and avoid unnecessary risks. Keep this instruction
manual in a safe place for future use.

CONTENTS:

1. Machine data
2. Safety instructions
3. Assembly
4. Use
5. Service & maintenance

1. MACHINE DATA

Introduction
The electric lawnmower is designated for lawn mowing,
i.e., maintenance of proper appearance of grass plots.

TECHNICAL SPECIFICATIONS

Voltage

AC 230 V

Input power

1000 W

Tool class

II

Motor rotation speed

3000 r/min

Operating mowing area

320 mm

Mowing height

25/40/55 mm

Grass reservoir capacity

30 dm

3

Weight

10,5 kg

FEATURES (FIG.1)

1. Body with a hanger
2. Motor cover
3. Rear cover
4. Grass reservoir
5. Lower parts of the handle
6. Upper part of the handle
7. Screw for the fastening of handle parts
8. Plastic nut
9. Main switch
10. Cable hanger
11. Rear wheel
12. Front wheel

The lawnmower is assembled from the body (1) made
from high-quality polymeric material as its basis; the
foundation of the body is an undercarriage with 4 wheels.
The motor safeguarded by a cover (2) is arranged in the
upper part of the body. A horizontally rotating knife is fas-
tened on the motor shaft. A reservoir for grass (4) made
of two parts, which is also called a bag, is arranged in
the rear part of the lawnmower behind the cover (3). The
handle of the lawnmower is composed of 3 parts made
from steel tube. Two lower side parts (5) are joined with
the upper part (6) with a screw (7) and plastic nut (8).
The voltage is connected and the lawnmower is started
