GB

English

TILE CUTTER

The DIY power tools are intended for non-professional use
up to 20 hours a month. The continuous operation must not
exceed 15 minutes and must be followed by 10 to 15 minutes
break.

TECHNICAL SPECIFICATIONS

Voltage

230 V~

Frequency

50 Hz

Power consumption

600 W S2: 30 min

No load speed

2950 min

-1

Max. depth of cut 90º

34 mm

Max. depth of cut 45º

18 mm

Cutting angle

0-45°

Ø Cutting blade

180 x 22.2 mm

Table dimensions

330 x 360 mm

Weight

8.2 kg

USE

This tool is suitable for cutting various wall and ; oor tiles with
a maximum tile size of 500 x 500 x 25 mm. The diamond
wheel can be replaced by the customer. It is not permitted to
use the tool for any other materials.

SAFETY INSTRUCTIONS

These instructions use the following images:

Means a risk of physical injury, danger of life or the
risk of damaging the machine if these instructions
are ignored.

Please read these instructions carefully before using this
tool. Ensure you are familiar with the tool and its operation.
Maintain this tool in accordance with the instructions to en-
sure it functions properly. Please keep these instructions for
use and the safety instructions with the tool.

SAFETY MEASURES

•  Check your powertool for damage before starting your

work, particularly the diamond blade. All parts must be = t-
ted properly and must meet all requirements in order to
guarantee the tool’s smooth operation. Any safety guards
or any lightly damaged parts must be checked to see if they
still function properly before continuing the use of the tool.
Moving parts, and the diamond blade guard in particular,
must be = tted properly and must not jam. Do not use tools
that cannot be switched on or off with the switch.

•  The diamond blade guard must not be jammed or re-

moved.

•  A jamming guard must be repaired immediately.
•  The riving knife must not be removed.

INSTALLING THE TILE CUTTER

•  The tile cutter may only be used as a = xed tool and should

be screwed down to a level and horizontal surface. Please
use the screw holes in the base of the machine.

•  The electrical supply must be connected to a 230 V

earthed wall socket. The mains voltage must comply with
the information on the type plate, and must be protected
by a circuit breaker.

•  Do not use the power cable to pull the plug from the sock-

et. Protect the cable against heat, oil and sharp objects.

Only use accessories and auxiliary equipment men-
tioned in the instructions for use or recommended
or mentioned by the manufacturer. Using other ac-

cessories or auxiliary equipment may carry a risk of injury for
you and others.

OPERATION

Fig. 1

•  Before starting the job, please ensure there is suf= cient

water in the water tray (4) i.e. the diamond blade runs
through the water. During the job, the water tray must be
topped up.

•  Do not start working before the maximum speed has been

reached.

•  The diamond blade must NEVER be exposed to sideways

pressure; they can break and the ; ying pieces become
projectiles!

•  Do not attempt to cut extremely small pieces from the

tiles. Always make sure that the full surface of the tile is
on the work table. The supplied mitre guide can be used
to push the tiles through the cutter. In the early stages of
cutting in particular, the tile must remain absolutely level
to avoid the tile moving up.

•  Do not overload your tool. It is better and safer to work

within the indicated power range. Do not cut materials
other than tiles.

•  Maintain your tools carefully. Keep the tools sharp and

clean in order to work properly and safely. Follow the
maintenance instructions and the instructions for replac-
ing the diamond blade.

•  Stand safely and maintain your balance. Avoid any un-

natural body angles. Remain alert and pay attention to
your work. Use common sense. Do not use the machine
when you cannot concentrate or when you are tired.

FULL-LENGTH ADJUSTABLE FENCE

Fig. 1

The fence (3) enables you to cut parallel to the cutting blade.
Set up: Loosen the knobs (7) and set the required distance.
Tighten the knobs on both sides of the work table. The mark-
ers determine the measurements (8).

MITRE GUIDE

Fig. 1

The mitre guide has a variable setting between 0° and 45°.
Loosen the knobs (5), set the mitre by tilting the table (1) up
until you have reached the required tilt. Tighten the knobs (5)
again on both sides of the worktable.
