14 ENGLISH

You can use the tool in the Torque Boost mode for

cutting thick branches or hard branches. To use the tool

in the Torque Boost mode, when the tool is turned off,

press the main power switch for a few seconds until the

main power lamp lights up in yellow.

NOTE:

 You can use the tool in the Torque Boost

mode up to 30 seconds. Depending on the usage

conditions, this mode shifts to the normal mode in

less than 30 seconds.

NOTE:

 If the main power lamp blinks in yellow when

you press the main power switch for a few seconds,

the Torque Boost mode is not available. In this case,

follow the steps below.
•

The Torque Boost mode is not available right

after the cutting operation. Wait for more than 10

seconds, and then press the main power switch

again.

•

If you use the Torque Boost mode several times,

the use of the Torque Boost mode is restricted to

protect the battery. If the Torque Boost mode is

not available after waiting for more than 10 sec-

onds, replace the battery cartridge with a fully

charged one, or recharge the battery cartridge.

NOTE:

 If the main power lamp lights up in red or

blinks in red or green, refer to the instructions for tool/

battery protection system.

NOTE:

 The Torque Boost mode cannot be used when

the battery cartridge BL1815N, BL1820, or BL1820B

is installed.

Switch action

WARNING:

For your safety, this tool is

equipped with lock-off lever which prevents the

tool from unintended starting. NEVER use the tool

if it runs when you simply pull the switch trigger

without pressing the lock-off lever. Return the

tool to our authorized service center for proper

repairs BEFORE further usage.

WARNING:

NEVER tape down or defeat pur-

pose and function of lock-off lever.

CAUTION:

Before installing the battery car-

tridge into the tool, always check to see that the

switch trigger actuates properly and returns to

the "OFF" position when released.

NOTICE:

Do not pull the switch trigger hard with-

out pressing the lock-off lever. This can cause

switch breakage.

To prevent the switch trigger from being accidentally

pulled, a lock-off lever is provided. To start the tool,

depress the lock-off lever and pull the switch trigger.

The tool speed increases by increasing pressure on the

switch trigger. Release the switch trigger to stop.

►

Fig.6:

1.

 Switch trigger

2.

 Lock-off lever

Checking the chain brake

CAUTION:

Hold the chain saw with both

hands when switching it on. Hold the top handle

with your right hand, the front handle with your

left. The bar and the chain must not be in contact

with any object.

CAUTION:

Should the saw chain not stop

immediately when this test is performed, the

saw may not be used under any circumstances.

Consult our authorized service center.

1.

Press the lock-off lever, then pull the switch trig-

ger. The saw chain starts immediately.

2.

Push the front hand guard forwards with the back

of your hand. Make sure that the chain saw comes to an

immediate standstill.

►

Fig.7:

1.

 Front hand guard

2.

 Unlocked position

3.

 Locked position

Checking the run-down brake

CAUTION:

If the saw chain does not stop

within two seconds in this test, stop using the

chain saw and consult our authorized service

center.

Run the chain saw then release the switch trigger com-

pletely. The saw chain must come to a standstill within

two seconds.

Adjusting the chain lubrication

You can adjust the oil pump feed rate with the adjusting

screw using the universal wrench. The amount of oil

can be adjusted in 3 steps.

►

Fig.8:

1.

 Adjusting screw

Carabiner (rope attachment point)

You can hang the tool by attaching the rope to the cara-

biner. Pull up the carabiner, and then tie it with the rope.

Electronic function

The tool is equipped with the electronic functions for

easy operation.
•

Soft start

The soft-start function minimizes start-up shock,

and makes the tool start smoothly.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

CAUTION:

Do not touch the saw chain with

bare hands. Always wear gloves when handling

the saw chain.
