Door removal

In order to obtain easier access to

the  oven  chamber  for  cleaning,  it  is

possible to remove the door. To do this,

tilt  the  safety  catch  part  of  the  hinge
upwards  (fi g.  A).  Close  the  door  lightly,

lift and pull it out towards you. In order

to fi t the door back on to the cooker, do
the inverse. When fi tting, ensure that the
notch of the hinge is correctly placed on
the protrusion of the hinge holder. After
the door is fi tted to the oven, the safety

catch should be carefully lowered down

again.  If  the  safety  catch  is  not  set  it
may  cause  damage  to  the  hinge  when
closing the door.

Tilting the hinge safety catches

removing the inner panel

1.  Using  a  fl at  screwdriver  unhook

the  up per  door  slat,  prying  it  gently  on
the sides (fi g. B).

2. Pull the upper door slat loose. (fi g.

B, C)



Ovens  in  cookers  marked  with

the letters Dp have stainless steel

sliding  telescopic  runners  attached  to

the wire shelf sup ports. The telescopic
runners should be removed and cleaned

together  with  the  wire  shelf  supports.
Before  you  put  the  baking  tray  on  the

telescopic runners, they should be

pulled  out  (if  the  oven  is  hot,  pull  out
the  telescopic  runners  by  hooking
the  back  edge  of  the  baking  tray  on

the bumpers in the front part of the

telescopic  runners)  and  then  insert
them together with the tray.

important!

Do not wash telescopic runners in a

dishwasher.

Removing telescopic runners

Installing telescopic runners

Oven  types  marked  with  the  letter

K in the model number are equipped
with liners co vered with special self–

cleaning  enamel.  The  enamel  removes

fat stains or leftover food automatically,

providing  they  are  not  dried  on  and
burnt  (food  and  fat  remnants  should

be removed when they are not dried on

and burnt to avoid a long self–cleaning
process).  To  activate  self–cleaning
switch  on  the  oven  for  1  hour,  setting
the  temperature  to  250°C.  If  remnants

of food are small the process can be
shortened.

If  the  self-cleaning  performance  is

noticeably reduced, replace the liners

with  new  ones:  take  out  the  wire

rails from the inside and unscrew the
catalytic enamel screw from the center
of the liner. New liners can be obtained
at service outlets.

Removal of catalytic liners
