Kuppersberg SR 669 B - Инструкция по эксплуатации - Страница 10

18

19

Technical passporT

english

english

Technical passporT

electric oven

electric oven

3. Pull the inner glass panel from its

seat  (in  the  lower  section  of  the  door).

Re move the inner panel (fi g. D).

4. Clean the panel with warm water

with some cleaning agent added.

Carry out the same in reverse order

to reassemble the inner glass panel. Its

smooth surface shall be pointed up-

wards.

important!

Do not force the upper strip in on

both sides of the door at the same time.

In  order  to  correctly  fi t  the  top  door

strip, fi rst put the left end of the strip on

the door and then press the right end in

until  you  hear  a “click”.  Then  press  the

left end in until you hear a “click”.

Removal of the internal glass panel.

3 glass.

Removal of the internal glass panel

2 glass.

replacement of the oven light bulb

in order to avoid the possibility of an

electric shock ensure that the appliance

is switched off before replacing the

bulb.



Set  all  control  knobs  to  the

position “



”/“0” and disconnect the

mains plug,



unscrew and wash the lamp

cover and then wipe it dry.



unscrew  the  light  bulb  from  the

socket, replace the bulb with a new one

–  a  high  temperature  bulb  (300°C)

with the follow ing parameters:

- voltage 230 V

- power 25 W

- thread E14.

Oven light bulb



Screw  the  bulb  in,  making  sure

it is prop erly inserted into the ceramic

socket.



Screw in the lamp cover.

regular inspections

Besides keeping the oven clean, you

should:



carry out periodic inspections of

the con trol elements and cooking units

of  the  cooker.  After  the  guarantee  has

expired you should have a technical

inspection  of  the  cooker  carried  out  at

a service centre at least once every two

years,



fi x any operational faults,



carry out periodical maintenance

of the cooking units of the oven.

Caution!

All  repairs  and  regulatory  activities

should be carried out by the ap propriate

service centre or by an appropriately

authorised fi tter.

O P e rat i O N  i N  Ca S e  O F  e m e rG e N CY

In the event of an emergency, you should:



switch off all working units of the oven



disconnect the mains plug



call the service centre



some minor faults can be fi xed by referring to the instructions given in the

table below. Before calling the customer support centre or the service centre check
the following points that are presented in the table.

PrOblem

reaSON

aCtiON

1. The appliance does not work. Break in power supply.

Check the household fuse box; if

there is a blown fuse replace it
with a new one.

2.  The  programmer  display

shows “0:00”.

The appliance was discon nected
from the mains or there was a
temporary power cut.

Set the current time

(see ‘Use of the programmer’).

3.  The  oven  lighting  does  not
work.

The bulb is loose or damaged.

Tighten  up  or  replace  the
blown  bulb  (see  ‘Cleaning  and
Maintenance’).
