21

ENGLISH

Electric oven

TECHNICAL PASSPORT

T E C H N I CA L  I N F O R M AT I O N

If the equipment does not work,

please contact the Technical Service
Department and advise them of the
problem, indicating:

1 Serial number (S-No)
2 Appliance model. (Model)

You will find this information on the

rating plate on the lower part of the
oven when the door is opened.

  The item that you have bought

meets the European directives on
electrical material safety (73/23/CEE)
and electromagnetic compatibility
(89/336/CEE).

AENOR  certifies  the  aptitude  of

this appliance for the function and

guarantees the truthfulness of all data

shown in the energy card.

I N S TA L L AT I O N

This information is intended for the

installer, as the person responsible for
assembly and electrical connection.

If you install the oven yourself,

the manufacturer will not be held
responsible for any possible damage.

Before Installation. Comments

Â

 To unpack the oven, pull the tab

located on the lower part of the box and
to move it, hold by the lateral handles
and never by the oven door handle.

Â

 A niche is required in the kitchen

unit as per the dimensions shown on

the  figure,  providing  a  minimum  depth

of 550 mm. (See technical drawings on
the page 14).

Â

  To  fit  multifunction  ovens  in

their locations, the back part of the
unit corresponding to the shaded area
of technical drawings, must not have
any projections (reinforcements, pipes,
sockets, etc). (See the page 14).

Â

 The adhesive used for the plastic

covering of kitchen furniture must be
able to withstand temperatures up to
85°C.

Electrical Connection. Legal
Requirements

The installer must check that:

Â

 The voltage and cycles of

the mains supply correspond to that
indicated on the rating plate.

Â

 The electrical installation can

stand the maximum power indicated on
the rating plate.

Â

 The connection diagram is

shown in the following figure.

Â

 The electrical connection has

adequate earthing in accordance with
regulations in force.

Â

 The connection must be carried

out with an omnipolar switch, of an
adequate size for the current drawn.
There must be a minimum aperture
between contacts of 3 mm to enable
disconnection in the case of emergency,
cleaning or bulb exchange. Under no
circumstances must the earth wire pass
through this switch.

After connecting the electricity,

check that all the electrical parts of the
oven are working.
