10

TEchnical passporT

English

gas oven

Installation Location

In order for the gas unit to work

properly it is essentital that the air

necessary for burning the gas flows into

the area naturally.

The installer must follow the safety

norms for the country of installation.

The  flow  of  air  into  the  area  must

come directly througy openings made in

the exterior walls. These openings must

have a free passage section of at least

100 cm2 (one or more openings can be

made.)

Products of combustion must be

exhausted through a hood connected to

a fume flue or directly outside.

In the event that it is not possible to

install the hood, it is necessary to use

an electric ventilation fan installed in

the outside wall or window of the area

so long as there is an opening for air

to enter the area in conformity with

current law.

This electric ventilation fan must

have  a  flow  capacity  sufficient  to

guarantee that 3 to 5 times the volume

of air in the room is xechanged every

hour.

Electrical Connection

Attention: do not connect to the

power  supply  before  you  have  finished

connecting the oven and cooktop.

Make sure that installation and

hook-up  are  performed  by  a  qualified

technician in accordance with the

manufacturer’s instructions and in

compliance with local regulations. The

installer is responsible for the correct

electrical connection and for the
observance of the safety rules.

The oven must be connected to the

electricity supply by means of an all-
pole disconnect switch with minimum
contact gap of 3 mm. The appliance
must be earthed by law.Do not use
multiple sockets or extensions.After the
oven has been installed, the electrial
componenets must be inaccessible.

Make sure that the voltage stated

on te appliance rating plate is the same
as the voltage in your home. The rating
plate is on the lower front edge of the
oven (visible with the door open.) If teh
power supply cable needs replacing,
make sure that it is replaced with a
cable similar to the one provided by
the  Manufacturer  (H05  RR-F  type)  and
that installation is performed by Service
Center  or  a  qalified  technician.  The
appliance is equipped with the cable for
the elecrical connection without plug.

The wires in the mains supply lead

are coloured in accordance with the
following code:

Green and Yellow - Earth
Blue - Neutral
Brown - Live

The connection must be made

as follows: The wire coloured Green
and Yellow must be connected to
the terminal marked ‘E’ or the earth
symbol or coloured green or green
and yellow. The wire coloured Blue
