Installation

The minimum distance between the supporting surface for the

cooking equipment on the hob and the lowest part of the

range hood must be not less than 50cm from electric cookers

and 65cm from gas or mixed cookers.

If the instructions for installation for the gas hob specify a

greater distance, this must be adhered to.

  Electrical connection

The mains power supply must correspond to the rating

indicated on the plate situated inside the hood. If provided with

a plug connect the hood to a socket in compliance with current

regulations and positioned in an accessible area, after

installation. If it not fitted with a plug (direct mains connection)

or if the plug is not located in an accessible area, after

installation,  apply a double pole switch in accordance with

standards which assures the complete disconnection of the

mains under conditions relating to over-current category III, in

accordance with installation instructions.

WARNING!

Before re-connecting the hood circuit to the mains supply and

checking the efficient function, always check that the mains

cable is correctly assembled.

The hood is provided with a special power cable ; if the cable

is damaged, request a new one from Technical Service.

Mounting

Before beginning installation:

•  Check that the product purchased is of a suitable size for

the chosen installation area.

•  Remove the charcoal (*) filter/s if supplied (see also

relative paragraph). This/these is/are to be mounted only

if you want lo use the hood in the filtering version.

•  Check (for transport reasons) that there is no other

supplied material inside the hood (e.g. packets with

screws (*), guarantees (*), etc.), eventually removing

them and keeping them.

Very heavy product; hood handling and installation must

be carried out by at least two persons.

Panel Assembly

(only for models where the panel is not supplied with the

hood)

 CAUTION!

Installation must be carried out only by qualified installers.

FOR THE INSTALLER: Responsibility for installation of the

hood, including verification of the conformity of any fixing kit

supplied with the product, is the sole responsibility of the

installer. Following is a non-exhaustive list of helpful

instructions for the installer:

-  use a fireproof PANEL (compliant with art. 30 of IEC/EN

60335-2- 31), suitable for the operating temperature (at

least 80°C) and humidity (at least 93%) reached during use;

í total weight of PANEL used should not exceed 4KG;

í secure the PANEL to the hood using the fixing points. See

the illustrations dedicated to assembly of the panel not

supplied with the hood.

í use suitable mechanical parts to fix the PANEL (not

included in the assembly kit). Elica denies all liability for

damage to persons or property resulting from incorrect

installation of the gypsum panels and/or product.
