Carbon filter warning
After 160 hours of operation, LED L5 flashes.
When this warning appears, it means that the installed carbon filter needs to be replaced.
To reset the warning, press and hold key T1 for 3”.

In the event that both warnings appear at the same time, LED L5 will alternately indicate the alarms by remaining
on for 3” and then flashing 3 times.
This condition can be reset by performing the procedure described above twice.
The first time resets the grease filter warning, the second time resets the carbon filter warning.
In standard mode, the carbon filter warning is not active.
If the hood is used in the filter version, it is necessary to enable the carbon filter warning.

Carbon filter warning activation:
Switch the hood OFF and simultaneously press and hold keys T1 and T4 for 3”.
The LEDs L1 and L2 will flash for 5”.
Carbon filter warning deactivation:
Switch the hood OFF and simultaneously press and hold keys T1 and T4 for 3”.
The LED L1 will flash for 2”.

Temperature alarm
The hood is equipped with a temperature sensor that activates the motor at speed 3 if the temperature
in the control panel area is too high.
The alarm condition is indicated by the LEDs L1, L2 and L3 flashing in sequence.
This condition remains until the temperature drops below the alarm threshold.
It is possible to exit this mode by pressing T1 or T2.
Every 30”, the sensor checks the temperature in the control panel area.

OPERATION

A

B

C

D

A= ON/OFF light switch.
B= ON/OFF switch and select speed 1 (in case of little steam and smoke).
B+C= Select speed 2 (in case of medium amount of steam and smoke).
B+D= Select speed 3 (in case of a lot of steam and smoke).

END-OF-LIFE DISPOSAL

This  device  is  marked  in  compliance  with  the  European  Directive  2012/19/EC  -  UK  SI  2013  No.3113,  Waste
Electrical and Electronic Equipment (WEEE). Make sure that this product is disposed of correctly. The user helps
prevent potential negative consequences for the environment and for health.

The  symbol  on  the  product  or  accompanying  documentation  indicates  that  this  product  should  not  be  treated  as
household  waste  but  should  be  handed  over  at  a  suitable  collection  point  for  the  recycling  of  electrical  and  electronic
equipment.  Dispose  of  it  in  accordance  with  local  regulations  for  waste  disposal.  For  further  information  about  the
treatment, recovery and recycling of this product, please contact your local authority, the collection service for household
waste or the shop from where the product was purchased.

RECOMMENDATIONS FOR USE

Recommendations  for  correct  use  in  order  to  reduce  the  impact  on  the  environment:  When  cooking  begins,  the  device
should be turned on at minimum speed, and left on for a few minutes even after cooking is complete. Increase the speed
only if there is a large quantity of fumes and steam, using the Booster function only in extreme cases. To keep the odour
reduction  system  running  efficiently,  replace  the  carbon  filter/s  when  necessary.  To  ensure  the  high  performance  of  the
grease  filter,  clean  it  when  necessary.  To  improve  efficiency  and  minimise  noise,  use  the  maximum  duct  diameter
indicated in this manual.
