10

3. Fault elimination

 by the user

Table 3

4. Fault elimination

 by the qualified installer

Table 4

2.12

Technical data

(the data on the unit identification plate are applicable)

Table 1

Type

DHM 3

DHM 4

DHM 6

Design

closed (pressurized)

closed (pressurized)

closed (pressurized)

Configuration

under-sink •

•

•

Reated pressure

MPa 1

1

1

T-piece with pressure hose

•

•

•

Rated capacity

l 0.1

0.1

0.1

Weight

kg 1.4

1.4

1.4

Rated power by 230 V

kW 3.5

4.4

5.7

Maximum electrical impendance Z

max

m

W

–

–

377

Rated voltage

1/N/PE ~ ... V 230

230

230

Rated current

A 15

19

25

Hot water output

∆ϑ

 = 25 K

l/min 2.0

2.5

3.3

Jet regulator SR 3

•

•

–

Jet regulator SR 5

–

–

•

Flow rate „ON“

> l/min 1.6

2.0

2.6

Flow rate „OFF“

< l/min 1.1

1.4

1.7

Automatic flow regulation

l/min 2.2

2.8

4.3

Pressure drop (during switch-on flow)

MPa 0.05

0.06

0.08

Max. inlet temperature

°C 25

25

25

Protection class in accordance with
DIN EN 60335

1

1

1

Protection mode in accordance with EN 60529 IP 25

IP 25

IP 25

Test mark, see unit identification plate

•

•

•

Water connections G 3/8 (surface installation)

•

•

•

Heating system - bare-wire

1100 Ω

cm

1)

•

•

•

Area of use: low-lime and limy water

•

•

•

Fault

Cause

Remedy

Flow too weak

Jet regulator furred or soiled.

Clean or if necessar y renew the fitting jet regu-
lator (see

„2.11 Special accessories“

).

Filter soiled.

Clean the filter in the cold water inlet

A

(

2

)

after shutting off the water supply.

Heating fails to switch on / no hot water.

No electrical power.

Check the fuse (house installation).

Heating system defective.

Measure heating system resistance, if necessar y
exchange the unit.

The pressure limiter has released

Determine and eliminate the cause for the fault.
Disconnect from power and relieve the pressu-
re.  Reactivate pressure limiter

E

 (

a

).

Fault

Cause

Remedy

No hot water despite fully opened hot water
fitting.

No electrical power.

Check the fuses in the house installation.

The turn on flow rate needed to switch on the
heating power has not been reached. Soiling or
furring of the jet regulator.

Clean or if necessar y renew the jet regulator
(see

„2.11 Special accessories“

).

Designation as

Areas of application for different water analysis reference temperatures
Standard

at 15 °C

at 20 °C

at 25 °C

resistance

conductivity

conductivity

Ω

cm

mS/m

µS/cm

≥ 1100

≤ 90,9

≤ 909

≥ 970

≤ 103

≤ 1030

≥ 900

≤ 111

≤ 1110

Table 2

1)

Specific electrical conductivity und specific electrical resistance
