only be turned in one direction;
ring illumination is not possible
in this case.

Vario appliances of the 20 0
series: The gas appliances are
protected against unintentional
activation because their control
knobs have to be both pressed
and turned.

L

LCD function display with
digital clock

The main functions activated
via the control knobs are always
visible on the bright LCD dis -
play in ovens of the 20 0 series.
The other touch key functions –
with their convenient setting
options – only become visible
when needed. The digital clock
can  also  be  used  as  a  shor t-
term  timer,  irrespective  of  the
function  set  for  the  appliance.
The  timer  functions  allow  both
the  length  of  the  cooking  pro -
cess  and  the  time  at  which
the appliance is to be switched
of f  to  be  programmed  up  to
24 hours  in  advance.

Liftmatic

The lift function in the BL 253
wall oven takes the stress out
of putting food in and out of the
oven. At the press of a button,
the bottom of the oven moves to
the individually saved position,
making it much easier to inser t
cookware or accessories. The
oven then closes at the press of
a button, and comes with crush
protection in both directions.
Hardly any energy is lost when
the door is opened – the heat
stays where it belongs.

Load sensor

Ensures  the  optimal  use  of
water, thereby reducing expend -
iture on water and electricity.
The system works with a rotation
sensor that measures the water
level in the pump well. It drops
as the load increases, because
more water is required for wet-
ting the dishes. This is detected
by the load sensor, which then
promptly triggers an appropriate
water intake. This prevents the
pump from running idle, thereby
avoiding the noise peaks that
would other wise occur.

Long -term timer

This function can keep dishes
warm in the oven at a selected
temperature (such as 8 5 °C)
for any period between 24 and
74 hours without having to oper-
ate the appliance. The in terior
lighting is switched off while the
function is in operation.

M

Memor y function

All settings are stored for a
few seconds  af ter  the  cooktop
is  switched  of f.  Consequently,
if the  appliance  is  switched
off unintentionally, all previously
entered  values  can  be  easily
restored.

Memor y recipes

This function, which is available
in both ovens and Combi - steam
ovens, allows you to save all
settings for a prepared dish so
that they can be easily retrieved
at any time. Six dishes can be
programmed, and up to five dif-
ferent steps or settings can

be saved for each dish – at the
press of a button after ever y
successful cooking step. If the
core temperature probe is
used, the respective core tem -
peratures are saved instead of
the cooking times. This ensures
the same delicious outcome
ever y time, even if por tion sizes
var y.

Microwave cooking

As  connoisseurs  know,  micro -
waves  have  become  indispen s -
able  –  for  ever y thing  from
heating  up  pre - prepared  por-
tions  of  food  to  making  hot
drinks in a glass, from bringing
food  from  the  refrigerator  to
ser ving temperature in no time
at all to the quick thawing of
frozen foods. The key element
of any microwave is the mag -
netron. This creates magnetic
waves, the energy of which is
evenly spread out in the cooking
compar tment  by  means  of  a
wave  distributor.  When  the
microwaves  hit  the  item  being
cooked,  they  cause  the  water
molecules  within  the  food  to
oscillate  at  high  speed. The
oscillating  molecules  create
friction, which in turn generates
heat. In microwaves, the heat
is therefore generated inside the
items being cooked – and not
from outside, as is the case in
conventional ovens.

Multiple glazing with
safety glass

The glazing in the oven door in -
volves up to four adjacent panes
of glass. The temperature of the
outer pane remains low, even
when the pyroly tic process is at
its ma ximum temperature.

N

No - Frost technology

If you own an appliance with
No - Frost technology, you can
forever say goodbye to the
tedious task of emptying and
defrosting the freezer compar t-
ment – a job which has to be
done about ever y six months
with conventional appliances.
What’s more, there is no more
frost build - up on frozen goods.

O

Options for dishwashers

Power: The main programmes
can be sped up considerably
with this option whenever items
– even those that are heavily
soiled – are needed again in a
hurr y. When combined with
Standard Eco, the best per form -
ance  (washing  and  dr ying ef fi -
ciency  class  A  according  to
Euro  label)  is  produced  in  a
mere  57  minutes  with  Vario
dishwashers, and in 59 minutes
with Power dishwashers. That’s
equivalent to a time saving of
up to 60 % . Auto programmes
run up to 30 % faster.

Intensive: For washing heavily
soiled pots and pans in the bot-
tom basket while gently clean -
ing fragile glasses in the upper
basket at the same time. By in -
creasing the spraying pressure
by 20%, as well as running addi -
tional wash cycles and heating
phases, this option transforms
the entire lower basket into
an intensive zone. At the same
time, the water pressure and
tempe r ature in the upper basket
are consistent with the selected
programme.

LCD function display with
 digital clock.

 The main func -

tions activated via the control
knobs are always visible on
the bright LCD display in the
20 0 series ovens.

The wood is untreated to pre -
vent the transfer of aromas,
while the edges are rounded to
protect the labels.

Presenters in aluminium
for displaying single bottles:
This accessor y is available as
a set.

Shelves in aluminium: The
per fect accessor y for wine cabi -
nets. Ideal for accommodating
decanters, carafes, open bottles,
as well as the humidor.

Inter val ventilation

When inter val ventilation is
 activated, the ventilation hood
automatically switches to the
preselected output level for five
minutes each hour. This means
that used or stale air can be
reg ularly ex tracted from the
room – also at night or during
long absences.

K

Knobs

Vario appliances of the 40 0
series: Since knobs need to
be both pressed and turned to
activate the corresponding
function, all appliances are pro -
tected against unintentional
switching on. Before a knob
can be turned, it must be
pushed through a clearly per-
ceptible stop position. The
temperature selection knobs on
electrical appliances may then
be turned in either direction,
even past the zero setting. The
setting selected for a cooking
zone using a par ticular knob
position is then retained. Active
cooking zones are indicated by
an orange illu minated ring. In
gas appliances, the knob can

Liftmatic.

 The lift function in

the BL 253 wall oven really
takes the stress out of putting
food in and out of the oven.
The bottom of the oven ex tends
at the press of a button.

Presenters in aluminium for displaying single bottles.

This accessor y

is available as a set of three.

.
