15.2. TRANSFERRING DATA TO YOUR PC

>>>

 P11

Install the PC-Sport software on your PC. Insert your VDO computer into
the docking station as shown (Fig. xxx) and connect the USB cable to
one of your computer‘s USB ports. Now start PC Sport
- Under „FILE“ select Import
- In Import select VDO series Z
Click on the Start button in the PC Sport program, then on the Z3 go to
setting mode
3 sec.

ç

Setting mode LANGUAGE SELECT

∂

  ƒ

PC LINK SELECT

‚

 PC LINK SENDING (the data transfer is indicated in
the display by changing numbers)

Now the PC receives the data of your VDO computer. Data transfer is
indicated by the changing numbers in the computer‘s display.

NOTE: When importing the

fi

les the PC-Sport program detects which

fi

les have already been imported. If you want to import this again you

must select it manually and con

fi

rm a warning query.

Now follow the instructions on saving

fi

les in the PC-Sport program.

Please see the PC Sport electronic user manual on the CD-ROM for all
additional information relative to planning and analysis of training units

15.3. SELECTION OF THE RECORDING INTERVAL
Your VDO computer offers two recording intervals (10 seconds or 20
seconds) for data recording.
Interval 1:

20 seconds

Maximum recording period:

100 hours

Selection of the recording interval:

Press  ¥ +

√

Interval 2:

10 seconds

Maximum recording period:

50 hours

Selection of the recording interval:

Press  ¥ +

√

Now the recording interval that has been set is shown in the display:
 DATA

RECORD

 INTERVAL
 10

SEC

 20

SEC

∂

  ƒ

UP/Down - changes to the other interval.

‚

Press M to con

fi

rm your selection.

ATTENTION: It is not possible to switch the recording interval during a
recording.
