EN - 15

appliance from unwanted button operation.

In cases where one or more buttons are

pressed for longer than 12 seconds, the

buzzer will sound for ten minutes to indicate

an incorrect operation and the appliance

will switch off. For example, an object may

be placed on a button, or there could be a

sensor failure and so on.

The safety switch-off will cause the hob to

go into S-mode and all heater displays will

flash “

F

”. If there is no incorrect operation

present, both the visual and audible signals

will disappear.

If residual heat is present, “

H

” will be

displayed on all other heater displays.

Over Temperature Switch-Off

Due to the controls being very close to the

heater in the middle of the front of the hob,

it can occur that an incorrectly placed pot

is not sensed by the sensor safety cut-off

therefore heating up the hob to a very high

temperature. This makes the glass and the

buttons dangerous to touch.

To prevent the hob control unit from

damage, the controls constantly monitor the

temperature and the hob will automatically

switch off if overheating occurs.

This will be indicated by the letter “

t

” in

the heater displays until the temperature

decreases.

Once the temperature has dropped, the

“

t

” in the heater display will disappear and

the hob control unit will revert back into

S-Mode. This means that the user can

reactivate the appliance by pressing   .

Operating Time Limitations

The hob control unit has a limitation on

the operating time. If the heat setting for a

heater has not been changed for a certain

time, the heater will switch off automatically.

A “

0

” will be displayed for 10 seconds,

however there may be some residual heat

present. The limit of the operating time

depends on the selected heat setting. If a

timer was associated with the heater, '00'

will be shown on the Timer Display for 10

seconds. After this, the Timer Display will

switch off.

After a heater automatically switches off, as

described above, the heater can be used

and the maximum operating time for this

heat setting is applied.

Residual Heat Functions

After all cooking processes, some heat

will be stored in the vitroceramic glass

called residual heat. The appliance can

calculate roughly how hot this glass is. If

the calculated temperature is higher than

+ 60 ° C, then this will be indicated in the

corresponding heater display for as long as

the calculated temperature remains above

+ 60 ° C, even after the appliance has been

switched off.

The residual heat indicator has the lowest

priority and is overwritten by every other

display value, including during safety

switch-off and the displaying of an error

code. When voltage is supplied to the hob

after a power interruption, the residual heat

display indicator will flash. If a heater had a

residual heat of greater than + 60 °C before

the power interruption occurred, the display

will flash while the residual heat remains

or until the heater is selected for another

cooking operation.

Hints and Tips

Important:

When ceramic heaters are

operated in higher heat settings, the

heated areas may be seen switching

on and off. This is due to a safety device,

which prevents the glass from overheating.

This is normal at high temperatures,

causing no damage to the hob and little

delay in cooking times.

WARNING:

•  Never operate the hob without

pans on the cooking zone.

•  Only use flat saucepans with a

sufficiently thick base.

•  Make sure the bottom of the pan is dry

before placing it on the hob.
