EN - 13

Triple Zone. The Triple Zone Indicator will

illuminate to confirm this.

Pressing   again will switch off the Triple

Zone of the heater. Each operation causes

a status change of the Dual and Triple

Zones in the following manner: dual zone

on/off, triple zone on, all extended zones

off, dual zone on/off, triple zone on, all

zones off, and so on.

Set Cooking Level with and without Heat

Boost

All heaters are equipped with the heat

boost function.

If the heat boost is required, set the heat to

0 using the slider then to level 9. Once level

9 has been reached, the display will flash

“

A

” alternating with the heat setting value

“

9

” to show the heat boost is active.

If the heat boost is active, the heater will

operate with maximum power for a period of

time dependent on the heat setting selected

before the heat boost was activated.

Once the heat boost time has ended, only

the heat setting will be indicated on the

heater display.

The heat boost can be deactivated by

pressing the Sliding Button until the heat

setting “

0

” is displayed.

Switching Off Individual Heaters

A selected heater can be turned off in 3

different ways:

•  Simultaneous pressing of the right

and left sides of the slider button

•  Reduction of the heat setting

to “

0

” using the slider button

•  Use of the timer switch-off function for

the corresponding heater.

Timer Function

The control can run a maximum of 4 heater-

assigned timers and 1 minute minder

timer (which is not assigned to a heater)

simultaneously. The timers can only be

used in B-Mode. A heater timer can only

be assigned to an active heater which has

been set to a level between 1 and 9. The

minute minder timer is independent of any

heater.

In order to use both functions, the timer

function must be activated using the

Activate/Deactivate Timer button  .

Pressing   for the fist time after activating

the heaters will control the minute minder

timer (no Cooking Zone Indicator will be

flashing, they are all on or off).

Pressing   for a second time will assign a

timer to one of the activated heaters. The

Cooking Zone Indicator will flash.

Pressing   again, will assign the next

timer in a clockwise direction to the next

active heater, and so on.

Minute Minder Timer

The minute minder timer can be operated

by pressing  , whether a heater has been

activated or not, and is selected only when

all Cooking Zone Indicators are either on or

off, i.e. none will be flashing.

The Timer Display will show “

00

” to

indicate the timer is active. The decimal

point on the Timer Display indicates that

 can now be used to set

the timer value.

The minute minder timer will begin counting

down once it has been set, it will not stop

if the appliance is switched off or if the Key

Lock function is activated.

Once it has reached zero, “

00

” will be

displayed on the Timer Display and the

buzzer will sound. Press any button to stop

the buzzer sounding.

Heater Timer

Heater Timers can only be set when a

heater has been activated, i.e. a heater

level must be set between 1 and 9.

Pressing   once will activate the minute

minder timer, pressing   again will assign

the timer to an activated heater. This will

be indicated by the corresponding Cooking

Zone Indicator flashing.

Pressing   for a third time, after setting

the first heater timer, will activate the timer

for the next active heater in a clockwise

direction. This will be indicated by its

corresponding Cooking Zone Indicator

flashing. Pressing

 will

allow the timer to be set a value for the

active heater.

The timer for the heater that was set first

will be indicated by the illumination of its

corresponding Cooking Zone Indicator.

Pressing   again will allow more timers to

be assigned to the other activated heaters.

The Timer Display will change, 10 seconds

after the last operation, to the timer that will

run out next. The number of timers that are

running will be indicated by the number of

illuminated Cooking Zone Indicators.

The timer values for the heater timer and

minute minder timer can be displayed by
