EN
28
Each action is verified by a beep.
Use the cursor slider (2) to adjust
power levels (0 - 9) by sliding your
finger over it. Sliding towards the right
increases the value, whereas sliding
towards the left decreases it.
It’s also possible to directly select a
power level by placing your finger
directly on a desired point of the cursor
slider (2)
In order to select a plate on
these models, directly touch the
cursor slider (
2
).
SWITCHING ON THE DEVICE
1
Touch the On touch key (1) for at
least one second. The touch control
will become active, a beep will be
heard and the indicators (3) will light
up displaying a “-”. If any cooking
area is hot, the related indicator will
flash an H.
If you do not take any action in the
next 10 seconds the touch control will
switch off automatically.
When the touch control is activated,
you can disconnect it at any time by
touching the touch button (1), even
if it has been locked (lock function
activated). The touch button (1)
always has priority to disconnect the
touch control.
ACTIVATING PLATES
Once the Touch Control is activated
with sensor (1), any plate can be
turned on by following these steps:
1
Slide the finger or touch in any
position of one of the cursors
“slider” (2). The zone has been
selected and simultaneuously the
power level will be set between 0
and 9. That power value will be
shown on the corresponding power
indicator and its decimal dot (4) will
keep light up during 10 seconds.
2
Use the cursor slider (2) to choose
a new cooking level between 0 and
9.
As long as the plate is selected, in
other words, with the decimal (4)
dot light up, its power level can be
modified.
TURNING OFF A PLATE
Using the touch slider key (2) lower
the power to level 0. The hotplate will
switch off.
When a hot plate is switched off an
H will appear in its power indicator
(3), if the glass surface of the related
cooking area is hot and there is a risk
of burns. When the temperature drops,
the indicator (3) switches off (if the hob
is disconnected), or otherwise a “-” will
light up if the hob is still connected.
TURNING ALL PLATES OFF
All plates can be simultaneously
disconnected by using the general on/
off sensor (1). All plate indicators (3)
will turn off. If the heating zone turned
off is hot, its indicator shows an H..
Pan detector
Induction cooking zones have a built-in
pan detector. This way, the plate will
stop working if there is no pan present
or if the pan is not suitable.
The power indicator (3) will show a
symbol to designate “there is no pan
” if, while the zone is on, no pan is
detected or the pan is not suitable
If a pan is taken off the zone while it
is running, the plate will automatically
stop supplying energy and it will
show the symbol for “there is no pan”.
When a pan is once again placed
on the cooking zone, energy supply
Fig.2
