 PROBLEM SOLVING

 10. AFTERCARE

Before calling out a Service Engineer please check the
following:

— that the plug is correctly inserted and fused;
If the fault cannot be identified switch off the appliance — do not
tamper with it — call the Aftercare Service Centre. The appliance
is supplied with a guarantee certificate that ensures that it will be
repaired free of charge at the Service Centre.

 9. PROBLEM SOLVING

The cooking zones do not simmer or only fry gently

• Only use flat-bottomed pans. If light is visible between the pan

and the hob, the zone is not transmitting heat correctly.

• The pan bottom should fully cover the diameter of the selected

zone.

The cooking is too slow

• Unsuitable pans are being used. Only use flatbottomed

utensils, that are heavy and have a diameter at least the same
as the cooking zone.

Small scratches or abrasions on the hob’s glass surface

• Incorrect cleaning or rough-bottomed pans are used; particles

like grains of sand or salt get between the hob and the bottom
of the pan. Refer to the “CLEANING” section; make sure that
pan bottoms are clean before use and only use smooth bottomed
pans. Scratches can be lessened only the cleaning is done
correctly.

Metal marks

• Do not slide aluminium pans on the hob. Refer to the cleaning

recommendations.

• You use the correct materials, but the stains persist.

Use a razor blade and follow the “CLEANING” section.

Dark stains

• Use a razor blade and follow the “CLEANING” section.

Light surfaces on the hob

• Marks from an aluminium or copper pan, but also mineral, water

or food deposits; they can be removed using the cream cleaner.

Caramelisation or melted plastic on the hob.

• Refer to the “CLEANING” section.

The hob does not operate or certain zones don’ t work

• The shunts are not positioned correctly on the terminal board.

Have a check made that the connection is done in compliance
with the recommendations.

“H” display, residual heat indicator, blinking.

• The electronic temperature is too high. A technician should verify

the fitting in compliance with the recommendations.

This appliance is marked according to the
European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly,
y o u   w i l l   h e l p   p r e v e n t   p o t e n t i a l   n e g a t i v e
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product.
The symbol on the product indicates that this
product may not be treated as household waste.

Instead it shall be handed over to the applicable collection point
f o r   t h e   r e c y c l i n g   o f   e l e c t r i c a l   a n d   e l e c t r o n i c   e q u i p m e n t
D i s p o s a l   m u s t   b e   c a r r i e d   o u t   i n   a c c o r d a n c e   w i t h   l o c a l
environmental regulations for waste disposal.
For more detailed information about treatment, recovery and
recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you
purchased the product.

 11. PROTECTION OF THE ENVIRONMENT

8 GB-IE
