WARNING

Noise. A degree of noise from the machine is not avoid

-

able.  Route  noisy  work  is  to  be  licensed  and  limits  for

certain periods. Keep rest periods and they may need to

restrict the working hours to a minimum.

For  their  personal  protection  and  protection  of  people

working nearby, an appropriate hearing protection shall

be worn;

Vibration. Always  wear  safety  and  anti-vibration  glove.

Excessive  vibration  may  cause  white  finger  disease  or

carpal  tunnel  syndrome.  If  you  notice  an  unpleasant

sensation  or  skin  discoloration  during  use  of  the  ma

-

chine on your hands once you stop working. Place an

adequate work breaks. And continual and regular us-

ers  should  monitor  closely  the  condition  of  their  hands

fingers.

WARNING

Contact with the trimmer cutting head while operating

can result in serious personal injury.

CUTTING TIPS

See Figure 6.

„

Keep the trimmer tilted toward the area being cut; this

is the best cutting area.

„

The  trimmer  will  cut  better  when  moved  from  left  to

right across the area to be cut; it is less effective when

moved from right to left.

„

Use the tip of the cutting line to do the cutting; do not

force cutting head into uncut grass.

„

Wire  and  picket  fences  cause  extra  cutting  line  wear,

even breakage. Stone and brick walls, curbs, and wood

may wear cutting line rapidly.

„

Avoid trees and shrubs. Tree bark, wood moldings,

siding, and fence posts can easily be damaged by the

cutting line.

„

Attach metal knob to the rubber hole on the rear handle

when in use, unlock the metal knob when not in use.

ADVANCING CUTTING LINE

See Figure 7.

While the string trimmer is operating, the cutting line

gets worn down and becomes shorter. This trimmer

is  equipped  with  bump  feed  line  advancement,  which

advances additional line once the head is bumped on the

ground while rotating. The cutting blade will cut the line to

keep an accurate cutting swath.

ADJUSTABLE CUTTING DIAMETER

  See Figure 8.

The trimmer is currently set at a 14 in. cutting swath. To

adjust to a cutting swath of 16 in.

„

Remove the battery from the string trimmer.

„

Remove both screws on the cut-off blade with a Phillips

screwdriver (not included).

„

Rotate the cut-off blade 180°.

„

Replace both screws in the cut-off blade.

Note:

Set the cut-off blade to 14 in. for greater runtime. Set

the cut-off blade to 16 in. for greater cutting area.

Note:

a  smaller  diameter  cutting  path  will  maximize  run

time and cutting speed, while a larger cutting path will help

complete the trimming task quicker.

LINE CUT-OFF BLADE

See Figure 8.

This trimmer is equipped with a line cut-off blade on the

grass  deflector.  For  best  cutting,  advance  line  until  it

is  trimmed  to  length  by  the  line  cut-off  blade.  Advance

line  whenever  you  hear  the  engine  running  faster  than

normal, or when trimming efficiency diminishes. This will

maintain best performance and keep line long enough to

advance properly.

WARNING

When servicing, use only identical replacement parts.

Use  of  any  other  parts  may  create  a  hazard  or  cause

product damage.

WARNING

To avoid serious personal injury, always remove the bat-

tery pack from the tool when cleaning or performing any

maintenance.

GENERAL MAINTENANCE

Before each use, inspect the entire product for damaged,

missing, or loose parts such as screws, nuts, bolts, caps,

etc.  Tighten  securely  all  fasteners  and  caps  and  do  not

operate this product until all missing or damaged parts are

replaced.
Avoid using solvents when cleaning plastic parts. Most

plastics  are  susceptible  to  damage  from  various  types  of

commercial solvents and may be damaged by their use.

Use clean cloths to remove dirt, dust, oil, grease, etc.

WARNING

Do not at any time let brake fluids, gasoline, petroleum-

based products, penetrating oils, etc., come in contact

with plastic parts. Chemicals can damage, weaken or

destroy plastic which may result in serious personal in-

jury.
