Appendix

Troubleshooting

The problems described below are not always caused by malfunctions. Check the TV again before having the
TV serviced.

Problem Possible

Solution

• No power.

• Check if you pressed

POWER

 on the remote control unit.

If the indicator on the TV lights up red, press

POWER

.

• Is the AC cord disconnected?
• Has the power been turned on?

• Unit cannot be

operated.

• External infl uences such as lightning, static electricity, etc., may cause improper operation. In

this case, operate the unit after fi rst turning the power off the TV or unplugging the AC cord
and re-plugging it in after 1 or 2 minutes.

• Remote control unit

does not operate.

• Is battery inserted with polarity (

e

,

f

) aligned? (See page 3.)

• Is battery worn out? (Replace with new battery.)
• Are you using it under strong or fl uorescent lighting?
• Is a fl uorescent light shining on the remote control sensor?

• Picture is cut off.

• Are screen mode adjustments such as picture size made correctly? (See page 9.)

• Strange colour, light

colour, or dark, or colour
misalignment.

• Adjust the picture tone. (See page 8.)
• Is the room too bright? The picture may look dark in a room that is too bright.
• Check the colour system setting. (See pages 5 and 7.)
• Check the HDMI auto view setting. (See page 6.)

• Power is suddenly

turned off.

• The unit’s internal temperature has increased.

Remove any objects blocking the vent or clean.

• Check the “Power Control” setting. (See page 9.)
• Is the sleep timer set? (See page 3.)

• No picture.

• Is the connection to external equipment correct? (See page 2.)
• Is the correct input selected?
• Is the “Picture settings” correct? (See page 8.)
• Is the antenna connected properly?
• Is “On” selected in “Audio only”? (See page 9.)

• No sound.

• Is the volume too low? (See page 3.)
• Make sure that headphones are not connected.

• The TV sometimes

makes a cracking
sound.

• This is not a malfunction. This happens when the cabinet slightly expands and contracts

according to changes in temperature. This does not affect the TV’s performance.

Cautions regarding use in high and low temperature environments

• When the unit is used in a low temperature space (e.g. room, offi ce), the picture may leave trails or appear slightly

delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.

• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near

a heater, as this may cause the cabinet to deform and the LCD panel to malfunction.
Storage temperature:

f

20°C to

e

60°C.

Clearing the password

If you forget the password, clear the password using the following procedure.

1

Press

MENU

 to display the MENU screen, and then press

c

/

d

 to select “Initial setup”.

2

Press

a

/

b

 to select “Child lock”, and then press

ENTER

 and the password input screen display.

3

If you enter “3001” using

0 – 9

, the “Child lock” setting menu will be displayed.

4

Enter the 4-digit number as a password using

0 – 9

. The new password is now set.

Specifi cations

Item                                                   Model

2T-C42BD1X

LCD panel

105.4 cm

Resolution

2,073,600 pixels (1920

g

 1080)

Video colour system

PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60

TV function

TV-standard

Analogue

PAL: B/G, D/K, I   SECAM: B/G, D/K, K/K

1

   NTSC: M

Digital

DVB-T2

Receiving
channel

VHF/UHF

44.25—863.25 MHz

CATV

S1—S41 ch (including Hyperband)

TV-tuning system

Auto Preset 99 ch

STEREO/BILINGUAL

NICAM: B/G, I, D/K   A2 stereo: B/G   MTS: M

Viewing angles

H : 176º  V : 176º

Audio amplifi er/Speakers

7.5 W

g

 2 / 4.3

g

 8.5 cm   2pcs

Terminals

Antenna input

UHF/VHF 75

q

 DIN type

SERVICE ONLY

 3.5 mm jack

HDMI 1 (HDMI/ARC)

HDMI input

HDMI 2 (HDMI)

HDMI input

INPUT 3

VIDEO in, AUDIO in

AUDIO OUT

AUDIO out, Headphone (  3.5 mm stereo)

USB

USB (DC5V 1.5A output)

OSD language

English/Simplifi ed Chinese/Arabic/French/Portuguese/Russian/Persian/
Thai/Malay/Vietnamese/Indonesian/Hebrew/Hindi

Power requirement

AC 110 — 240 V, 50/60 Hz

Power consumption

80 W (0.5

W Standby)

Dimensions

without stand

956 (W)

g

 569 (H)

g

 81 (D) mm

with stand

956 (W)

g

 646 (H)

g

 248 (D) mm

Weight without stand (with stand)

7.4 kg (7.6  kg)

Operating temperature

0°C — 40°C

• As a part of policy of continuous improvement, SHARP reserves the right to make design and specifi cation changes for

product improvement without prior notice. The performance specifi cation fi gures indicated are nominal values of production
units. There may be some deviations from these values in individual units.

• Specifi cation may differ depending on the selected country.

CAUTION

• Installing the Liquid Crystal Television requires special skill that should only be performed by qualifi ed service personnel.

Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or
mounting that results in accident or injury.

• Carefully read the instructions that come with the bracket before beginning work.
