Overview-Installation

Overview of TV Buttons

Audio Input
jacks

Video Input
jack

Selecting
Input
source

Headphone
jack

Displaying
the menu
system

Volume
control
buttons

Programme Up or
Down Buttons
(Selects TV
channels)

Lift up the door
flap with

mark to reveal
the control
panel.

Standby/On
Timer indicator
Normal-Green
Standby-Red
Timer-Amber

On/Off

switch

Inserting Batteries into the Remote Control

Make sure you insert the supplied batteries observing the correct polarities.
Always remember to dispose of used batteries in an environmental friendly way.

SONY CORPORA

TION

  J

AP

AN/4

DR

Y B

ATTER

Y R6/3(NS

) S

IZE"AA" 1

.5

v

For more details of VCR connection, please refer to the section “Connecting
Optional Equipment” of this instruction manual (see page 15).

VCR

Scart lead is optional

or

Connecting the Aerial and VCR

Connecting cables are not supplied.
