Karcher WD 3 P-I (1.629-891.0) - Инструкция по эксплуатации - Страница 10

– 6

–

Risk of fire. Do not vacuum up any burning or glow-
ing objects.

–

The appliance may not be used in areas where a
risk of explosion is present.

–

Immediately switch the appliance off or pull the
power plug if foam forms or liquids escape!

–

Do not use abrasives, glass or universal cleaners!
Never immerse the appliance in water.

Certain materials may produce explosive vapours or
mixtures when agitated by the suction air!
Never vacuum up the following materials:

–

Explosive or combustible gases, liquids and dust
particles (reactive dust particles)

–

Reactive metal dust particles (such as aluminium,
magnesium, zinc) in combination with highly alka-
line or acidic detergents

–

Undiluted, strong acids and alkalies

–

Organic solvents (such as petrol, paint thinners, ac-
etone, heating oil).

In addition, these substances may cause the appliance
materials to corrode.



DANGER

Pointer to immediate danger, which leads to severe in-
juries or death.

몇

WARNING

Pointer to a possibly dangerous situation, which can
lead to severe injuries or death.

몇

CAUTION

Pointer to a possibly dangerous situation, which can
lead to minor injuries.

ATTENTION

Pointer to a possibly dangerous situation, which can
lead to property damage.

Illustrations on fold-out page!



These operating instructions de-

scribe the multi-purpose vacuum

cleaners listed on the front cover.



The illustrations show the maximum equipment;

depending on the model, there are differences in

equipment and supplied accessories.

When unpacking the product, make sure that no acces-

sories are missing and that none of the package con-

tents have been damaged. If you detect any transport

damages please contact your dealer.

included in the scope of delivery

possible accessories

Illustration



To connect the suction hose during vacuuming.

Illustration



Position I

: Suction or blowing

Position 0

: Appliance is switched off

Illustration



Position I

: Suction or blowing

Position II

: Automatic vacuuming with connected

electric tool

Position 0

: Appliance and the connected electric

tool are switched off

Note

: Observe the maximum connected load (see

Chapter "Technical data").

Illustration



To connect an electric tool.



To carry the appliance or to remove the appliance

head after unlocking.

Illustration



To store the mains cable.

Illustration



Connect the suction hose to the blower connection,

this will activate the blower function.

Illustration



Pull out to open, push in to lock.

Illustration



To rest the floor nozzle during work interruptions.

Illustration



The accessories compartment allows the storage

of suction pipes and suction nozzles on the appli-

ance.

Illustration



The steering rollers are located in the waste con-

tainer when the appliance is delivered. These must

be attached prior to starting up the appliance.

Note

: Do not use a filter bag for wet vacuuming!

Illustration



Recommendation

: To vacuum fine dust, use the

filter bag.

Hazard levels

Description of the Appliance

Suction hose connection

ON/OFF switch for appliance

(without built-in socket)

ON/OFF switch for appliance

(with built-in socket)

Machine socket

Carrying handle

Cable hook

Blowing connection

Container closure

Parking position

Accessory mount

Steering roller

Filter bag

10

EN
