DISASSEMBLING

1.  Turn the power ‘Off’ at the power outlet and unplug the cord.
2.  Slightly tilt the pulp container and slide away from the juicer – figure 8.
3.  Place fingers under the bottom of the twin-locking handles and lift to

release – figure 9.

4.  Lift the juicer cover from the juice collector/bowl – figure 10.
5.  Place fingers under the rim of the stainless steel blade and filtering bas-

ket and lift out – figure 11.

IMPORTANT:

Juicing blades are very sharp, handle juicing filter basket with care when
removing, replacing and cleaning.

6.  Lift the juice collector/bowl from the motor base – figure 12.

WICHTIG

Die Klingen im Filterkorb sind sehr scharf! Gehen Sie damit vorsichtig um,
fassen Sie nicht an die Klingen, wenn Sie den Entsafter zusammenbauen,
auseinandernehmen oder reinigen.

7.   Nehmen Sie den Filterbecher von der Basis ab (Abb. 12).

CARE AND CLEANING

NOTE:

Ensure that the juicer is unplugged from the power outlet prior to cleaning.

Quick clean

For easy cleaning, ensure that immediately after use that the juicer is disas-
sembled and that each removable part is rinsed under running water, remov-
ing any wet pulp and then allow to air dry.

Thorough cleaning

Disassemble the juicer and place all removable parts aside, see ‘Disassem-
bling’ section. Rinse the juice collector/bowl, juicer cover, pulp container
and food pusher under running water and wash with warm, soapy water.
Rinse well. Using the nylon cleaning brush supplied with the juicer, hold the
stainless steel blade and filtering basket under running water and brush the
outside of the basket first. Then with the basket still under running water,
brush the inside of the basket in an anti-clockwise direction, removing the
pulp. To ensure the stainless steel blade and filtering basket is free of all
remaining pulp, hold it up to light and ensure that the holes in the filtering
basket are not blocked.

IMPORTANT:

Juicing blades are very sharp, handle juicing filter basket with care when
removing, replacing and cleaning.

IMPORTANT:

Never immerse the motor base in water or any other liquid.

IMPORTANT:

Do not use chemical, steel wool or abrasive cleaners to clean the outside
of the juicer, as these will scratch the stainless steel and die-cast metal
surface.

To clean the motor base

Using a damp soft sponge with a mild detergent, wipe the motor base clean.

MAINTENANCE AND TROUBLESHOOTING

• For safety’s sake, the appliance should be repaired only by qualified per-

sonnel at an authorized service center.

• The warranty does not cover damage due to unauthorized repairs or im-

proper use of the appliance.

• Never use a defective appliance or if you see visible damage to the ap-

pliance, cord or plug.

• Never disassemble the appliance yourself or insert any foreign objects

into any of the openings of the appliance.

Problem

Possible cause

What to do

Juicer will not
start when speed
is selected.

The juicer hasn’t
been assembled cor-
rectly.

See "Accembling" section

The juicer mo-
tor appears to
struggle during
operation.

Pulp container is full. Empty the pulp container.

Pulp is caught in the
juicer cover.

Stop juicing, remove the juic-
er cover and clean out pulp.
See ‘Disassembling and ‘Care
and Cleaning’ sections.
Try a slower juicing action –
guide the food pusher down
the feed chute in a slow
downward motion.

Stainless steel blade
and filtering basket is
blocked with excess
pulp.

After extended juicing of
fibrous fruit and vegetables
the mesh on the
filtering basket may need to
be cleaned. Stop juicing, dis-
assemble the juice extractor
and clean the filtering basket.
See ‘Disassembling.

The selected juicing
speed is incorrect.

See ‘Juicing speed guide’.
