ENGLISH

(Original instructions)

ENGLISH

(Original instructions)

  Discard the battery pack with due care for the environment.

Charge STANLEY battery packs only with designated

STANLEY chargers. Charging battery packs other than

the designated STANLEY batteries with a STANLEY

charger may make them burst or lead to other dangerous

situations.

 Do not incinerate the battery pack.

Package Contents

The package contains:
1 Hammer drill
1 Charger
2 Batteries (S2) or 1 Battery (S1)
1 Instruction manual

NOTE:

 Battery packs and chargers are not included with

N-models.
• Check for damage to the tool, parts or accessories which may

have occurred during transport.
• Take the time to thoroughly read and understand this manual

prior to operation.

FEATURES (Fig. A)
1.

 Trigger Switch

2.

 Forward/Reverse Button

3.

 Torque Adjustment Collar

4.

 Gear shifter

5.

 Keyless Chuck

6.

 Battery Release Button

7.

 Battery pack

8.

 LED Work Light

9. Function collar

INTENDED USE

This hammer drill is designed for light fastening and drilling

applications.

DO NOT

 use under wet conditions or in presence of flammable

liquids or gases.
This hammer drill is a professional power tool.

DO NOT

 let children come into contact with the tool. Supervision

is required when inexperienced operators use this tool.
• This product is not intended for use by persons (including

children) suffering from diminished physical, sensory or mental

abilities,  or  for  lack  of  experience  and/or  for  want  of  knowledge

or skills unless they are supervised by a person responsible for

their safety. Children should never be left alone to play with this

product.

Electrical Safety

The electric motor has been designed for one voltage

only. Always check that the battery pack voltage

corresponds to the voltage on the rating plate.

Also make sure that the voltage of your charger

corresponds to that of your mains.
Your STANLEY charger is double insulated in accordance with

EN 60335; therefore no earth wire is required.
 If the supply cord is damaged, it must be replaced by a

specially prepared cord available through the STANLEY service

organization.

Using an Extension Cable

An extension cord should not be used unless absolutely

necessary. Use an approved extension cable suitable for the

power input of your charger (see

Technical Data

). The minimum

conductor size is 1 mm2; the maximum length is 30 m.
When using a cable reel, always unwind the cable completely.

Assembly and adjustments

WARNING:

  Prior  to  assembly  and  adjustment,  always

remove the battery pack. Always switch off the tool

before inserting or removing the battery pack.

WARNING:

 Use only STANLEY battery packs and

chargers.

Inserting and Removing the Battery Pack from the Tool

(fig. C)

WARNING: To reduce the risk of serious personal

injury, place the forward/reverse button in the lock-

off position or turn tool off and disconnect battery

pack before making any adjustments or removing/installing

attachments or accessories. An accidental start-up can

cause injury.
NOTE:

Make sure your battery pack (7) is fully charged.

TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE

1. Align the battery pack with the rails inside the handle.
2. Slide it firmly into place until you hear the lock snap into place.

TO REMOVE THE BATTERY PACK FROM THE TOOL

1. Press the release button (6) and firmly pull the battery pack out

of the tool handle.
2. Insert battery pack into the charger as described in the charger

section of this manual.

OPERATING INSTRUCTIONS

Safety warnings and instructions: Drills
WARNING:

 Always observe the safety instructions and

applicable regulations.

WARNING: To reduce the risk of serious personal

injury, place the forward/reverse button in the lock-

off position or turn tool off and disconnect battery pack

SC121
