a wooden mallet, as shown. Tighten the screw once again by

turning in a counterclockwise direction.

Drill Operation

WARNING:

To reduce the risk of serious personal injury,

turn tool off and disconnect tool from power source

before  making  any  adjustments  or  removing/installing

attachments or accessories.

WARNING: To reduce the risk of personal injury,

ALWAYS

 ensure workpiece is anchored or clamped

firmly. If drilling thin material, use a wood “back-up” block

to prevent damage to the material.
Turn the collar to the drill bit symbol for drilling. Select the desired

speed/torque range using the gear shifter to match the speed and

torque to the planned operation.
• Use sharp drill bits only. For WOOD, use twist drill bits, spade

bits, or hole saws. For METAL, use high-speed steel (HHS) twist

drill bits or hole saws.
• Always apply pressure in a straight line with the bit. Use enough

pressure to keep drill biting, but do not push hard enough to stall

the motor or deflect the bit.
• Hold tool firmly with both hands to control the twisting action

of the drill.

WARNING:

 The drill may stall if overloaded causing

a sudden twist. Always expect the stall. Grip the drill

firmly with both hands to control the twisting action and

avoid injury.

• IF DRILL STALLS, it is usually because it is being overloaded

or improperly used. RELEASE TRIGGER IMMEDIATELY,

remove drill bit from work, and determine cause of stalling.

DO  NOT  CLICK  TRIGGER  ON  AND  OFF  IN  AN  ATTEMPT

TO START A STALLED DRILL — THIS CAN DAMAGE THE

DRILL.

• To minimize stalling or breaking through the material, reduce

pressure on drill and ease the bit through the last fractional part

of the hole.
• Keep the motor running when pulling the bit back out of a drilled

hole. This will help prevent jamming.

• With variable speed drills there is no need to center punch

the point to be drilled. Use a slow speed to start the hole and

accelerate by squeezing the trigger harder when the hole is deep

enough to drill without the bit skipping out.

Hammer drill operation (Fig. D)

1. Turn the collar (9) to the hammer drill symbol.
2. Select the high speed setting by sliding the selector forward

(towards the chuck). Important: Use carbide tipped or masonry

bits only.

3.  Drill  with  just  enough  force  on  the  hammer  to  keep  it  from

bouncing excessively or “rising” off the bit. Too much force will

cause slower drilling speeds, overheating and lower drilling rate.

4. Drill straight, keeping the bit at a right angle to the work. Do

not exert side pressure on the bit when drilling as this will cause

clogging of the bit flutes and a slower drilling speed.
5. When drilling deep holes, if the hammer speed starts to drop

off, pull the bit partially out of the hole with tool still running to help

clear debris from the hole.

NOTE:

 A smooth, even flow of dust from the hole indicates proper

drilling rate.

Operation as a Screwdriver

Select the desired speed/torque range using the dual range gear

shifter on the top of tool to match the speed and torque to the

planned operation.
Insert the desired fastener accessory into the chuck as you would

any drill bit. Make a few practice runs in scrap or unseen areas to

determine the proper position of the clutch collar.

MAINTENANCE

Your STANLEY power tool has been designed to operate over a

long period of time with a minimum of maintenance. Continuous

satisfactory operation depends upon proper tool care and regular

cleaning.

WARNING: To reduce the risk of serious personal

injury, place the forward/reverse button in the lock-

off position or turn tool off and disconnect battery

pack before making any adjustments or removing/installing

attachments or accessories.

 An accidental start-up can cause

injury.

The charger and battery pack are not serviceable. There are no

serviceable parts inside.

Lubrication

Your power tool requires no additional lubrication.

Cleaning

WARNING:

 Blow dirt and dust out of the main housing

with dry air as often as dirt is seen collecting in and

around the air vents. Wear approved eye protection and

approved dust mask when performing this procedure.

WARNING:

 Never use solvents or other harsh chemicals

for cleaning the non-metallic parts of the tool. These

chemicals may weaken the materials used in these

parts. Use a cloth dampened only with water and mild soap.
