ENGLISH

(Original instructions)

ENGLISH

(Original instructions)

• Do not use an extension cord unless it is absolutely

necessary.

Use of improper extension cord could result in risk of

fire, electric shock, or electrocution.

• Do not place any object on top of charger or place the

charger on a soft surface that might block the ventilation

slots and result in excessive internal heat.

Place the charger

in a position away from any heat source. The charger is ventilated

through slots in the top and the bottom of the housing.

• Do not operate charger with damaged cord or plug

— have

them replaced immediately.

• Do not operate charger if it has received a sharp blow,

been dropped, or otherwise damaged in any way.

Take it to

an authorised service centre.

• Do not disassemble charger; take it to an authorized

service centre when service or repair is required.

 Incorrect

reassembly may result in a risk of electric shock, electrocution

or fire.
• In case of damaged power supply cord the supply cord must be

replaced immediately by the manufacturer, its service agent or

similar qualified person to prevent any hazard.

• Disconnect the charger from the outlet before attempting

any cleaning. This will reduce the risk of electric shock.

Removing the battery pack will not reduce this risk.

• NEVER

 attempt to connect 2 chargers together.

• The charger is designed to operate on standard household

electrical power. Do not attempt to use it on any other

voltage.

This does not apply to the vehicular charger.

SAVE THESE INSTRUCTIONS
Chargers

The SC121 accept 10.8V batteries.

These chargers require no adjustment and are designed to be as

easy as possible to operate.

Charging Procedure (fig. B)

1. Plug the charger (10) into an appropriate outlet before inserting

battery pack.
2. Insert the battery pack (7) into the charger. The red (charging)

light will blink continuously indicating that the charging process

has started.
3. The completion of charge will be indicated by the red light

remaining ON continuously. The pack is fully charged and may

be used at this time or left in the charger.

NOTE:

To ensure maximum performance and life of Li-Ion

batteries, charge the battery pack fully before first use.

Charging Process

Refer the tables below for the state of charge of the battery pack.

HOT/COLD PACK DELAY

When the charger detects a battery that is hot, it automatically

delays charging until the battery has cooled.
When the charger detects a battery that is cold, it automatically

delays charging until the battery has warmed.
The red light will continue to blink, but a yellow indicator light

will be illuminated during this operation. Once the battery has

cooled, the yellow light will turn off and the charger will resume

the charging procedure.

Electronic protection system

Li-Ion batteries are designed with an Electronic Protection System

that will protect the battery against overloading, overheating or

deep discharge.
The tool will automatically turn off if the Electronic Protection

System engages. If this occurs, place the Li-Ion battery on the

charger until it is fully charged.

Important Safety Instructions for All Battery Packs

When ordering replacement battery packs, be sure to include

catalog number and voltage.
The battery pack is not fully charged out of the carton. Before

using the battery pack and charger, read the safety instructions

below. Then follow charging procedures outlined.

READ ALL INSTRUCTIONS
• Do not charge or use battery in explosive atmospheres,

such as in the presence of flammable liquids, gases or dust.

Inserting or removing the battery from the charger may ignite the

dust or fumes.

• Never force battery pack into charger. Do not modify

battery pack in any way to fit into a non-compatible charger

as battery pack may rupture causing serious personal injury.

• Charge the battery packs only in STANLEY chargers.

• DO NOT

 splash or immerse in water or other liquids.

• Do not store or use the tool and battery pack in locations

where  the  temperature  may  reach  or  exceed  40  ˚C  (105  ˚F)

(such as outside sheds or metal buildings in summer).

WARNING:

Never attempt to open the battery pack for

any reason. If battery pack case is cracked or damaged,

do not insert into charger. Do not crush, drop or damage

battery pack. Do not use a battery pack or charger that has

received a sharp blow, been dropped, run over or damaged in

any way (i.e., pierced with a nail, hit with a hammer, stepped

on). Electric shock or electrocution may result. Damaged battery

packs should be returned to service centre for recycling.

CAUTION:

 When not in use, place tool on its side on a

stable surface where it will not cause a tripping or falling

hazard. Some tools with large battery packs will stand

upright on the battery pack but may be easily knocked over.
