Original instructions

EN

done previously. DO NOT CONTINUE to use under

these conditions. Follow the charging procedure. The

Li- ion battery can be charged at any time without re-

ducing its service life. Interrupting the charging proce-

dure does not damage the battery.

▪

If the battery pack does not charge properly:

  (1) Check current at receptacle by plugging in a lamp

or other appliance.

  (2) Move charger and battery pack to a location where

the surrounding air temperature is approximately 15°C–

25°C).

  (3) If charging problems persist, take or send the tool,

battery pack and charger to your local service centre.

▪

To ensure the longest battery life and best battery

performance, always charge the battery when the air

temperature is between 15–25°C. Do not charge the

battery pack when the temperature is below 5°C, or

above 40°C. This is important. Failure to observe this

safety rule could cause serious damage to the bat-

tery pack.

▪

The charger and battery pack may become warm to

touch while charging. This is a normal condition, and

does not indicate a problem.

▪

To prevent overheating, do not charge battery packs

in direct sunlight in hot weather or near heat sources.

▪

Do not charge inside a box or container of any kind.

The battery must be placed in a well ventilated area

during charging.

▪

When the battery is defective, liquid can escape and

come into contact with adjacent components. Check

any parts concerned. Clean such parts or replace

them, if required.

▪

Do not incinerate the battery pack even if it is seriously

damaged or can no longer hold a charge. The battery

pack can explode in a fire.

▪

To facilitate the cooling of the battery pack after use,

avoid placing the charger or battery pack in a warm

environment such as in a metal shed, or an uninsu-

lated trailer.

BATTERY CHARGING

(Fig. 1)

▪

Insert the plug of the charger in the socket. The green

LED light on the charger indicator (11) will start to glow

thus indicating mains voltage.

▪

Insert the battery (5) in the charger socket (10).

▪

A new battery will work properly after five cycles of

charging and discharging. Charge and discharge a

battery, which is not used for a long time, for two to

three times to function well.

▪

When the battery working time is remarkably short de-

spite full charging, the life of the battery may be over.

Replace the battery immediately.

Charging indication:

▪

The green LED light starts to glow upon plugging the

charger in the mains.

▪

The green LED light starts to blink after the battery

has been placed in the charger, thus indicating the

beginning of the charging process.

During the charging process the charger and battery

might become warm. This is a normal condition, and

does not indicate a problem.

▪

The green LED light starts to glow constantly after

completion of charging.

The charger features thermal overload protection for the

battery. Nevertheless we recommend withdrawing the

battery from the charger upon expiring of the charging

time. You may use additionally an electric timer in order

to control the charging time.

State description

Constantly glowing

green light

Ready-to-charge state

When there is no battery pack in-

serted in the charger, green light

indicates ready-to-charge state.

Blinking green light:

Charging

Battery pack is being charged.

Constantly glowing

green light

Fully charged battery pack

When there is a battery pack in-

serted in the charger, green light

indicates that it is fully charged.

Constantly glowing

red light

Battery temperature is out of

the admissible charging tem-

perature range 0÷45

o

C

Move the charger with battery to

another premises with appropri-

ate environmental temperature.

Once the temperature reaches the

admissible charging temperature,

the charger automatically switches

to charging mode.

Blinking red light:

Fault

In failure mode charging is not pos-

sible. The reason for failure may

be one of the following:

▪

Battery pack is not inserted

properly;

▪

Battery pack terminals are

dirty;

▪

Damaged battery pack;

▪

Unrecognized battery pack.

Know your product

Before using the power tool, familiarize yourself with all

operating features and safety requirements.

Use the tool and accessories only for the applications

intended. All other applications are expressly ruled out.
  1.  Keyless chuck

  2.   Speed selector switch

  3.  Forward/reverse switch

  4.  Battery release buttons

  5.   Battery

  6.  ON/OFF trigger switch

  7.   Battery state indicator

  8.  LED light

  9.   Torque adjustment collar

 10.  Charger

 11.   LED charge state indicator

 12.  Operation mode selector switch
