English

TRANSLATION OF THE ORIGINAL

7.

d.   Remove any adjusting key or wrench before starting

the machine.

A keychain attached to a rotating part of a power tool power

tool may result in personal injury.

e.   Maintain strong support on the ground and keep well

balanced at all times use.

This allows better control of the power tool in unexpected

situations.

f.

Do not wear loose clothing, large objects or jewellery

that may get caught by moving parts.

Keep your hair and gloves away from moving parts. Loose

clothes, jewellery or long hair can get caught in moving parts.

g.   When devices or connections for dust extraction and

collecting equipment are provided , ensure these are

well connected and used properly.

The use of these devices can reduce dust related hazards.

4. Use and care of power tools

a.   Do not force the power tool. Use the correct power

tool for your application.

The correct power tool will do the job better and safer at the

rate for which it was intended for.

b.   Do not use the power tool if the switch does not turn

to "closed" and "open".

Any power tool that can not be controlled by the switch is

dangerous and must be repaired.

c.   Remove the plug from the power source and / or

battery before making any adjustments, changing

accessories, or storing power tools.

Such preventative safety measures reduce the risk of starting

the tool accidentally.

d.    Store idle power tools out of reach of children and do

not allow the use of power tools to people unfamiliar

with tools or the instructions.

Power tools are dangerous in the hands of untrained users.

e.   Keep tools sharp and clean.

The Properly maintained cutting tools with sharp cutting

edges are less likely to bind and are easier to control.

f.   Use the power tool, accessories and tool tips, etc..

in

accordance with these instructions, taking into account the

working conditions and the work to develop. Use of the

power tool for applications other than those intended could

result in a hazardous situation.

5. Technical  Support

a.   This power tool complies with the requirements of

appropriate security.

Repairs should only be carried out by a qualified profesional,

using original spare parts, otherwise there could be a

significant risk to the user.

Additional safety precautions provided by the manufacturer.

1.

WARNING!

 Do not use the machine for purposes other

than which it was designed.

2.

It is essential to have adequate artificial lighting in work areas

where ambient light is insufficient.

3.

Recommended working temperature between 0 and 40° C

and between 0.8 and 1.1 bar ( maximum humidity 95%).

4.

Before starting operations use protective gloves, ear

protectors and goggles.

5.

When unpacking the machine and after each use, check that

there are no bumps or deformations or broken parts/cables.

If you establish broken parts/cables, do not use the mixer

and immediately contact the manufacturer.

6.

Do  not  use  the  mixer  to  work  with  flammable  liquids  or

gases, or any other material other than cement mortar or

glue. Also, do not use the tool if the presence of flammable

liquids or gases in the vicinity.

7.

Attach the mixer paddle firmly during use.

8.

Keep your tools clean and free of grease, oils and debris

dry cement or mortar. When cleaning do not use solvents

or aggressive chemicals, read "Cleaning and mainteance" for

more information.

WORKSPACE

C. INSTRUCTIONS FOR USE

INSTRUCTIONS

When unpacking the machine check carefully for damaged or

broken parts. If you find any damaged or faulty parts, replace with

original spare parts and contact our RUBI  after -sales service.

Mounting the mixing head

1.    The mixing head is supplied removed from the mixer. To

mount the head, screw and tighten the two parts that form it

using the 22mm wrench supplied with the machine.

2.    Screw the top of the mixing head with the output shaft (M14)

of Rubimix-7.

3.    Tighten  the  fixed  22  mm  wrench.  hard  to  screw  the  mixing

head , turning to the left and use the auxiliary key of 19 mm.

in the output shaft to fix the mixing head, rotating clockwise.

Preflight

4.    Ensure that the voltage of the power supply match the voltage

and frequency indicated on the nameplate of the machine.

5.    Machines can also be connected to 230V 210V / 240V.

Machines can be connected to 110V 100V / 120.

6.    Use only mixing heads suggested in this manual with a

maximum diameter of 140 mm.

COMMISSIONING

Connection

7.     Before operating the machine enter the head in the product

mix.

8.     To  start  the  machine  first  press  the  release  button  on  the

switch and then press the power switch.  Always work with

the on/off switch fully applied.

9.   Regulation- Turn  the  switch  located  on  the  left  side  of  the

machine to get the desired speed.

The speed depends on the material to be mixed and can be

determined by testing.

10.   Depending on the consistency of the material and mixing

amount should determine the various mixing heads to be

used.

If the product is a low viscosity mix use a mixing head with a

left hand helix. If instead product is a high viscosity mix, use a

mixing head propeller, clockwise.

11.    Work at low speed at the beginning of mixing and increase

speed rotation as the mixture is gaining consistency.

12.    Always hold the machine with both hands, up and down the

mixer to remove.

Move the machine across the container during the mixing

process to ensure an even finish.

Attention!

If while running the mixer it butts the container surface, this

could produce a strong kick.

13.    Work the material until it has reached the proper degree
