9 ENGLISH

OPERATION

CAUTION:

Always insert the battery cartridge

all the way until it locks in place.

 If you can see the

red indicator on the upper side of the button, it is not

locked completely. Insert it fully until the red indicator

cannot be seen. If not, it may accidentally fall out of

the tool, causing injury to you or someone around

you.

CAUTION:

When the speed comes down

extremely, reduce the load or stop the tool to

avoid the tool damage.

Always use the side grip (auxiliary handle) and firmly

hold the tool by both side grip and switch handle during

operations. Failure to do so may result in the loss of

control of the tool and potentially severe injury.

►

Fig.15

Screwdriving operation

CAUTION:

Adjust the adjusting ring to the

proper torque level for your work.

CAUTION:

Make sure that the driver bit is

inserted straight in the screw head, or the screw

and/or driver bit may be damaged.

First, turn the action mode changing ring so that the

arrow on the tool body points to the

 marking.

Place the point of the driver bit in the screw head and

apply pressure to the tool. Start the tool slowly and then

increase the speed gradually. Release the switch trigger

as soon as the clutch cuts in.

NOTE:

 When driving wood screw, pre-drill a pilot hole

2/3 the diameter of the screw. It makes driving easier

and prevents splitting of the workpiece.

Hammer drilling operation

CAUTION:

There is a tremendous and sud-

den twisting force exerted on the tool/drill bit

at the time of hole breakthrough, when the hole

becomes clogged with chips and particles, or

when striking reinforcing rods embedded in the

concrete.

First, turn the action mode changing ring so that the

arrow on the tool body points to the

 marking. The

adjusting ring can be aligned in any torque levels for

this operation.

Be sure to use a tungsten-carbide tipped drill bit.

Position the drill bit at the desired location for the hole,

then pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.

Do not apply more pressure when the hole becomes

clogged with chips or particles. Instead, run the tool at

an idle, then remove the drill bit partially from the hole.

By repeating this several times, the hole will be cleaned

out and normal drilling may be resumed.

Blow-out bulb

Optional accessory

►

Fig.16:

1.

 Blow-out bulb

After drilling the hole, use the blow-out bulb to clean the

dust out of the hole.

Drilling operation

First, turn the action mode changing ring so that the arrow

points to the

 marking. Then proceed as follows.

Drilling in wood

When drilling in wood, the best results are obtained with wood

drills equipped with a guide screw. The guide screw makes

drilling easier by pulling the drill bit into the workpiece.

Drilling in metal

To prevent the drill bit from slipping when starting a

hole, make an indentation with a center-punch and

hammer at the point to be drilled. Place the point of the

drill bit in the indentation and start drilling.

Use a cutting lubricant when drilling metals. The excep

-

tions are iron and brass which should be drilled dry.

CAUTION:

Pressing excessively on the tool

will not speed up the drilling.

 In fact, this excessive

pressure will only serve to damage the tip of your drill

bit, decrease the tool performance and shorten the

service life of the tool.

CAUTION:

Hold the tool firmly and exert care

when the drill bit begins to break through the

workpiece.

 There is a tremendous force exerted on

the tool/drill bit at the time of hole break through.

CAUTION:

A stuck drill bit can be removed

simply by setting the reversing switch to reverse

rotation in order to back out. However, the tool

may back out abruptly if you do not hold it firmly.

CAUTION:

Always secure workpieces in a

vise or similar hold-down device.

CAUTION:

If the tool is operated continuously

until the battery cartridge has discharged, allow

the tool to rest for 15 minutes before proceeding

with a fresh battery.

MAINTENANCE

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before attempting to perform inspection or

maintenance.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.

To maintain product SAFETY and RELIABILITY, repairs, carbon

brush inspection and replacement, any other maintenance or

adjustment should be performed by Makita Authorized or Factory

Service Centers, always using Makita replacement parts.
