14

HOLDER

The power tool provides convenient holder (

6

) that allows to e.g.

hang the tool on a tool belt when working at heights.

OPERATION AND MAINTENANCE

MAINTENANCE AND STORAGE

•

Cleaning the device after each use is recommended.

•

Do not use water or any other liquid for cleaning.

•

Clean the power tool, battery and charger with a dry cloth or

blow through with compressed air at low pressure.

•

Do not use any cleaning agents or solvents, they may damage

plastic parts.

•

Clean ventilation holes in the motor casing regularly to

prevent device overheating.

•

In case of excessive commutator sparking, have the technical

condition of carbon brushes of the motor checked by a

qualified person.

•

Store the power tool and its equipment in a dry place, beyond

reach of children.

•

Store the device with the battery removed.

All defects should be repaired by service workshop authorized

by the manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS

Cordless impact driver

Parameter

Value

Battery voltage

18V DC

Range of idle rotational speed

0-2200 min

-1

Tool chuck

6,35 mm (¼ ‘’)

Max. torque

180 Nm

Protection class

III

Weight

1,2 kg

Year of production

2021

Graphite Energy+ System Battery

Parameter

Value

Battery

58G001

58G004

Battery voltage

18 V DC

18 V DC

Battery type

Li-Ion

Li-Ion

Battery capacity

2000 mAh

4000 mAh

Ambient temperature range

4

0

C – 40

0

C

4

0

C – 40

0

C

Charging time for charger 58G002

1 h

2 h

Weight

0,400 kg

0,650 kg

Year of production

2021

2021

Graphite Energy+ System Charger

Parameter

Value

Charger type

58G002

Supply voltage

230 V AC

Power supply frequency

50 Hz

Charging voltage

22 V DC

Max. charging current

2300 mA

Ambient temperature range

4

0

C – 40

0

C

Charging time of the battery 58G001

1 h

Charging time of the battery 58G004

2 h

Protection class

II

Weight

0,300 kg

Year of production

2021

NOISE LEVEL AND VIBRATION PARAMETERS
Noise and vibration information

Parameters of produced noise level, such as sound pressure level

Lp

A

 and sound power level Lw

A

 with measurement uncertainty K

are specified below in this manual, in compliance with EN 60745.

Vibration values a

h

 and measurement uncertainty K are

determined in accordance with EN 60745-2-2 and specified

below.

Vibration level specified below in this manual was measured in

accordance with measurement procedure defined in EN 60745

and can be used to compare power tools. It can also be used for

initial assessment of exposure to vibrations.

Specified vibration level is representative for main applications

of the power tool. Vibration level may change if the power tool is

used for other purposes, with different working tools or will not

be maintained properly. The abovementioned factors may lead

to higher exposure to vibrations during whole working time.

To precisely define exposure to vibrations, include periods when

the power tool is switched off and when it is switched on but

not used for working. This way total exposure to vibrations may

be significantly lower. Use additional safety measures to protect

the user against results of exposure to vibrations, such as: power

tool and working tool maintenance, proper hand temperature

conditions, good work organisation.
Sound pressure level: Lp

A

= 95,1 dB (A) K=3dB (A)

Sound power level: Lw

A

= 106,1  dB (A) K=3dB (A)

Vibration acceleration: a

h

= 15,87 m/s

2

  K = 1,5 m/s

2

ENVIRONMENTAL PROTECTION

Electrical equipment must not be disposed off

with household waste and, instead, should be

utilized at appropriate facilities. Information

on utilization can be provided by the product

vendor or the local authorities. Waste electrical

and electronic equipment contains substances

that are not neutral to the natural environment.

Equipment that is not recycled constitutes a

potential hazard to the environment and to

human health.

Li-Ion

Do not dispose the batteries with household

wastes, do not throw in fire or water. Damaged

or worn out batteries should be properly recycled

in accordance with applicable directive for

battery disposal.. Batteries should be returned to

collection points fully discharged, if the batteries

are not completely discharged, they must be

protected against short circuits. Used batteries

can be returned free of charge at commercial

locations. The buyer of the goods is obliged to

return the used batteries.

* Right to introduce changes is reserved.
