12
• Do not use damaged or modified battery.
Damaged or
modified batteries may behave unpredictably, causing fire,
explosion or risk of injuries.
• Do not expose the battery to humidity or water.
•
Always keep the battery away from sources of heat. Do not
leave the battery for a long time in high temperature (in
direct sunlight, in proximity of heaters and wherever the
temperature exceeds 50°C).
• Do not expose the battery to fire or excessive temperature.
Exposure to fire or temperature above 130°C may cause explosion.
CAUTION!
Temperature of 130°C can be also defined as 265°F.
• Observe all charging instructions. Do not charge the
battery in temperature outside of range defined in the
rating data table from the instruction manual.
Incorrect
charging or charging in temperature outside of defined range
may damage the battery and increase the risk of fire.
BAT TERY REPAIRS
• Do not repair damaged batteries.
Battery can be repaired
only by the manufacturer or in an authorised workshop.
• When disposing of the worn out battery, take it to a service
point where you can utilize such dangerous wastes.
SAFETY REGULATIONS FOR THE CHARGER
• Do not expose the charger to humidity or water.
Ingress of
water into the charger increases risk of electric shock. Use the
charger only in dry rooms.
•
Disconnect the charger from power supply before starting any
maintenance or cleaning.
• Do not use the charger when placed on flammable
surface (e.g. paper, textiles) or in proximity of flammable
substance.
Greater charger temperature when charging
increases risk of fire.
• Check condition of the charger, cable and plug before each
use. Do not use the charger if any damage is found. Do not
try to disassemble the charger.
All repairs should be made at
an authorized service workshop. Improper charger assembly may
cause electric shock or fire.
•
Children or persons who are physically, emotionally or
mentally disabled and other persons, whose experience or
knowledge is insufficient to use the charger while following all
safety rules should not use the charger without supervision of
person responsible for their safety. Otherwise there is a risk of
improper use and injuries in consequence.
• When the charger is not in use, it should be disconnected
from the mains network.
• Observe all charging instructions. Do not charge the
battery in temperature outside of range defined in the
rating data table from the instruction manual.
Incorrect
charging or charging in temperature outside of defined range
may damage the battery and increase the risk of fire.
CHARGER REPAIRS
• Do not repair damaged charger.
The charger can be repaired
only by the manufacturer or in an authorised workshop.
• When disposing of the worn out charger, take it to a service
point where you can utilize such wastes.
CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures and
additional safety systems are used, nevertheless there is
always a small risk of injuries at work.
Li-Ion batteries may leak, set on fire or explode when
heated to high temperature or short-circuited. Do not store
the batteries in a car in hot and sunny days. Do not open
the battery. Li-Ion batteries contain electronic protection
devices that, if damaged, may cause fire or explosion of the
battery.
Explanation of used symbols
1
2
3
4
7
5
Max.
50°C
6
8
9
10
11
1.
Read instruction manual, observe warnings and safety
conditions therein.
2.
Use protective goggles and hearing protectors.
3.
Keep the tool away from children.
4.
Protect against rain.
5.
Use indoors, protect from water and moisture.
6.
Recycling.
7.
Protection class 2.
8.
Segregated waste collection.
9.
Do not throw cells into fire.
10.
Hazardous to water environment.
11.
Do not allow to heat above 50°C.
CONSTRUCTION AND USE
The impact driver is a battery-powered tool. The drive consists
of DC commutator motor with permanent magnets. The impact
driver is used for tightening and undoing screws and bolts in
wood, metal or plastics. High speed allows to use the device
widely for self drilling screws, and high torque allows to use
the device for long screws in wood. The device can be well used
at heights and in hard to reach areas. High torque mechanism
creates the torque as short, high peaks of circumferential
impact, and tool reactions towards the operator's hands during
tightening is low.
Use the power tool in accordance with the manufacturer’s
instructions only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on
the drawing pages of this manual.
1.
Tool chuck
2.
Fixing sleeve of the tool chuck
3.
Casing
4.
Handle
5.
Direction selector switch
6.
Holder
7.
Battery
8.
Battery lock button
9.
Switch
10.
Lighting
11.
LED diodes
12.
Charger
13.
Button for battery level indication
14.
Battery level indicator (LED)
* Differences may appear between the product and drawing.
