Technical data

Cordless percussion drill

PDC 18/4

Motor voltage

18 V

No-load speed*

1st gear

0 - 400 rpm

2nd gear

0 - 850 rpm

3rd gear 0 - 1850 rpm

4th gear 0 - 3800 rpm

Max. torque

Soft material (wood)

40 Nm

Hard material (metal)

60 Nm

Adjustable torque**

1st gear 1.2 - 11.5 Nm

2nd gear 0.8 - 7.2 Nm

3rd gear 0.6 - 4.7 Nm

4th gear 0.6 - 2.6 Nm

Chuck clamping range

1.5 - 13 mm

Drill diameter max.

Wood

50 mm

Metal

13 mm

Fastening in pine

max. ∅

10 mm

Tool holder in drill spindle

1/4"

Weight (incl. additional handle, battery pack BP 18 Li 6,2 AS and chuck) as per EP­

TA procedure 01:2014

2.4 kg

Weight with Centrotec, without additional handle, without battery pack.

1.3 kg

* Speed specifications with fully charged bat­

tery pack.

** The maximum speed is reduced in the lower

torque stages (values in clockwise rotation).

5

Functional description

[1-1]

LED light switch

[1-2]

LED lamp

[1-3]

Bit store

[1-4]

On/Off switch

[1-5]

Clamping sleeve

[1-6]

Drilling/impact drilling selector

switch

[1-7]

Gear switch

[1-8]

Torque thumbwheel

[1-9]

Right/left switch

[1-10]

Belt clip

[1-11]

Button for releasing the battery pack

[1-12]

Insulated gripping surfaces (grey

shaded area)

[1-13]

Capacity display button on battery

pack

[1-14]

Capacity indicator

Accessories shown or described are not always

included in the scope of delivery.

The specified illustrations appear at the begin­

ning of the Operating Instructions.

6

Commissioning

6.1

Changing the battery pack

Inserting the battery pack [2 A]

Removing the battery pack [2 B]

The battery pack is ready to use straight out of

the box and can be charged at any time.

6.2

Light and battery capacity indicator

The LED on the lamp

[1-2]

 is both a light

and a battery capacity indicator .

► Press the LED light switch

[1-1]

:
