14

English

Noise

information

Always  wear  ear  protection  if  the  sound

pressure exceed 85 dB(A).

Declaration of

conformity

We declare under our sole responsibility that the

product  described  under  "Power  tool  specifications"

is in conformity with all relevant provisions of the di-

rectives 2006/42/EC including their amendments and

complies with the following standards: EN 60745-1,

EN 60745-2-1�

Certification

Wu Cunzhen

manager

Merit Link International AG

Stabio, Switzerland, 30�05�2017

General

safety rules

WARNING  -  To  reduce  the  risk  of  injury,

user must read instruction manual!

WARNING! Read all safety warnings and

all instructions.

 Failure to follow the warn-

ings and instructions may result in electric

shock, fire and / or serious injury.

Save all warnings and instructions for future refer-

ence.

The term "power tool" in the warnings refers to your

mains-operated (corded) power tool or battery-operat-

ed (cordless) power tool�

Work area safety

•

Keep  work  area  clean  and  well  lit.

 Cluttered or

dark areas invite accidents�

•

Do not operate power tools in explosive atmos-

pheres, such as in the presence of flammable liq-

uids, gases or dust.

 Power tools create sparks which

may ignite the dust or fumes�

Power tool specifications

Low speed drill

BM-1050 M

Power tool code

[127 V ~50/60 Hz]

[230 V ~50/60 Hz]

741770

742937

Rated power

[W]

1050

Power output

[W]

590

Amperage at voltage

127 V [A]

230 V [A]

7�5

4�9

No-load speed

[min

-1

]

550

Chuck tightening range

[mm]

[inches]

1,5-13

1/16"-33/64"

Drill chuck thread

[mm]

[inches]

1/2"x20 UNF

Drilling output:

- steel

[mm]

[inches]

13

33/64"

- wood

[mm]

[inches]

40

1-37/64"

Weight

[kg]

[lb]

3,3

7�2

Safety class

Sound pressure

[dB(A)]

87

Acoustic power

[dB(A)]

98

Weighted vibration

[m/s

2

]

12,9
