 English |

13

Bosch Power Tools

1 609 92A 1CG | (23.6.15)

Safety Warnings for Drills



Use auxiliary handle(s), if supplied with the tool.

Loss

of control can cause personal injury.



Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord.

Cutting ac-

cessory contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an
electric shock.



Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance.

Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.



When working with the machine, always hold it firmly
with both hands and provide for a secure stance.

The

power tool is guided more secure with both hands.



Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.



Always wait until the machine has come to a complete
stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.



Products sold in GB only:

 Your product is fitted with a

BS 1363/A approved electric plug with internal fuse
(ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place by an
authorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.

Products sold in AUS and NZ only:

 Use a residual current

device (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for drilling in wood, metal, ceramic
and plastic. Machines with electronic control and right and
left rotation are also suitable for screwdriving and tapping.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Keyless chuck *
(only on power tools 3 601 AB2 002/
3 601 AB2 040: keyless chuck with securing ring *)

2

Front sleeve

3

Rear sleeve

4

Lock-on button for On/Off switch

5

Thumbwheel for speed preselection

6

On/Off switch

7

Rotational direction switch

8

Gear selector

9

Auxiliary handle (insulated gripping surface)

10

Depth stop

11

Handle (insulated gripping surface)

12

Chuck key *

13

Key type drill chuck *

14

Screwdriver bit *

15

Universal bit holder *

16

Securing screw for für keyless chuck/key type drill chuck

17

Open-end spanner **

18

Clamping sleeve *

19

Securing ring *

20

Holding ring *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

** Commercially available (not included in the delivery scope)

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-1.

Typically the A-weighted noise levels of the product are:
Sound pressure level 82 dB(A); Sound power level 93 dB(A).
Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-1:
Drilling into metal: a

h

= 4.5 m/s

2

, K = 1.5 m/s

2

,

Screwdriving: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

,

Tapping: a

h

< 2.5 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
