 English |

17

Bosch Power Tools

1 609 929 W68 | (21.6.11)

Working Advice

Cutting Tiles (see figures H1 – H3)

– Insert the tile cutter

14

 into the sawing slot of the guide rail

4

 above stop

15

.

The arrow on the tile cutter must face you.

– Pull the tile cutter

14

 over the complete tile with uniform

pressure.

– Remove the tile cutter

14

 from the guide rail

4

.

– Turn the locking lever

10

 of the guide rail leftward and fold

the guide rail

4

 upward.

– Place the break-off cones

16

 on a firm surface.

Place the tile on the break-off cones in such a manner that
the break-off cones are positioned below the cutting line
and at the edges of the tile.
For diagonal cuts, the break-off cones should be posi-
tioned below the cutting line and somewhat further toward
the inside.

– Apply both of your thumb balls at the same time to the out-

er sides of the tile until the tile breaks.

Practical Advice

For working instructions and practical advice on the PLS 300
saw station, log onto:

www.bosch-do-it.com/pls300

For further questions, please refer to our customer hotline:

Great Britain

Tel: +44 (0844) 736 0107

Australia, New Zealand

Phone: +61 (01300) 307 044

Maintenance and Service

Maintenance and Cleaning

If the saw station should fail or become damaged despite the
care taken in manufacture and testing, repair should be car-
ried out by an authorised customer services agent for Bosch
power tools.
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the type plate of
the saw station.

Cleaning

Remove dust and chips after each working procedure by
blowing out with compressed air or with a brush.

Warranty Condition

Through faulty usage, sawing into the guide rail

4

 or bridge

8

can occur. No warranty claims whatsoever shall arise thereof,
as this does not affect the function of the saw station.

After-sales Service and Customer Assistance

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:

www.bosch-pt.com

Our customer service representatives can answer your ques-
tions concerning possible applications and adjustment of
products and accessories.

Great Britain

Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: +44 (0844) 736 0109
Fax: +44 (0844) 736 0146
E-Mail: boschservicecentre@bosch.com

Problem

Cause

Corrective Measure

Tile does not break along the
cutting line

Scoring line not continuous from front to
end

Apply more pressure (uniformly) when scoring the
tiles and score over the complete surface

Tile cutter

14

 incorrectly inserted

Insert tile cutter correctly (see figure H1)

Surface structure of tile uneven

Apply more pressure (uniformly) when scoring and
increase the scoring (cutting) speed

Break-off cones incorrectly positioned
when breaking the tile

Position break-off cones below the cutting line and
at the edges of the tile (see figure H3)
For diagonal cuts, position the break-off cones
somewhat further toward the inside

Scoring line not continuous from front to
end

Increase scoring pressure when cutting the tiles
