| English
1 609 929 W68 | (21.6.11)
Bosch Power Tools
f
Use the saw station only for cutting the materials listed
under Intended Use.
Marble or granite as well as tiles with
a rough surface structure and natural stone tiles cannot be
cut.
Product Description and Specifica-
tions
Intended Use
PLS 300:
Together with the power tool, the sawing station is
intended for sawing straight lengthway and crossway cuts in
boards and profiles of hardwood and softwood, as well as alu-
minium and plastic.
Horizontal mitre angles from a maximum of – 45 ° to +45 ° as
well as bevel angles from a maximum of 0 ° to 45 ° can be set.
The sawing station is intended for operation exclusively with
jigsaws from the Bosch PST DIY program.
f
Only use the saw blades recommended by Bosch (see
page 129).
When using saw blades that are too thin, dan-
ger is given that the cut runs out of centre.
PLS 300 Set, PTC 1:
Together with the tile cutter, the sawing
station is intended for cutting ceramic and nonvitreous tiles to
a maximum thickness of 10 mm.
Horizontal mitre angles from a maximum of – 45 ° to +45 ° can
be set.
Product Features
The numbering of the product features refers to the illustra-
tion of the sawing station on the graphics pages.
PLS 300
1
Base unit
2
Scale for mitre angle (horizontal)
3
Locking knob for height adjustment
4
Guide rail with sawing slot
5
Side stops of the guide rail
6
Support extension
7
Additional support
8
Bridge
9
End stop for bevel cuts
10
Locking lever of the guide rail
11
Alignment mark
12
Locking knob for various mitre angles
13
Mitre angle indicator
PTC 1*
14
Tile cutter
15
Stop with scale
16
Break-off cones
* only in combination with PLS 300
Technical Data
f
Only use the saw blades recommended by Bosch (see
page 129).
When using saw blades that are too thin, dan-
ger is given that the cut runs out of centre.
Sawing station
PLS 300
PLS 300 Set
(PLS 300 + PTC 1)
Article number
3 603 M04 0..
3 603 M04 1..
Sawing
– Max. cutting length for crossway cuts (90 ° )
– Max. cutting height
– Mitre/Bevel Angle
Horizontal
Vertical
mm
mm
°
°
315
25
r
45
r
45
315
25
r
45
r
45
Cutting tiles
– Max. cutting length for crossway cuts (90 ° )
– Max. cutting height
– Mitre/Bevel Angle
Horizontal
mm
mm
°
–
–
–
340
10
r
45
Weight according to EPTA-Procedure 01/2003
kg
3.4
3.4 + 0.2
Dimension of suitable saw blades
Max. overall length
mm
100
Max. toothed length
mm
76
OBJ_BUCH-1219-002.book Page 14 Tuesday, June 21, 2011 2:15 PM
