20

 | English

1 609 92A 4DA | (08.10.2018)

Bosch Power Tools

Application tool

Material

Application

Scraper, fixed

Carpets, mortar, con-
crete, tile adhesive

Scraping on a hard surface;
example: Removing mortar, tile adhesive, concrete
residue and carpet adhesive residue

Scraper, flexible

Carpet adhesive, paint
residue, silicone

Flexible scraping on a soft surface;
example: Removing silicone joints, carpet adhesive
residue and paint residue

Bi-metal segment
serrated blade

Insulation material, insula-
tion boards, floor panels,
impact sound insulation
boards, cardboard, car-
pets, rubber, leather

Precise cutting of soft materials;
example: Cutting insulation boards to size, cutting pro-
truding insulation material to length so that it is flush with
the surface

TC-Riff sanding fin-
ger

Wood, paint

Sanding of wood or paint in hard-to-reach areas without
sanding paper;
example: Sanding off paint between window shutter slats,
sanding wooden flooring in corners

TC-Riff plunge cut
saw blade

Fibreglass, mortar, wood Plunge cuts in extremely abrasive materials;

example: Routing of thin mosaic tiles

HCS universal joint
cutter

Expansion joints, window
putty, insulation materials
(rock wool)

Cutting soft materials;
example: Cutting silicone expansion joints or window
putty

Bi-metal plunge cut
saw blade for wood
and metal

Softwood, hardwood,
veneered boards, plastic-
coated boards, non-
hardened nails and
screws

Fast, deep plunge cuts in wood and metal;
example: Fast cutting of wood containing nails, deep
plunge cuts in laminated boards and precise shortening of
door frames

Bi-metal plunge cut
saw blade for wood
and metal

Wood, abrasive wood-
based materials, plastics,
hardened nails and
screws, non-ferrous metal
pipes

Fast, deep plunge cuts in wood, abrasive wood-based ma-
terials and plastics;
example: Fast cutting of non-ferrous metal pipes and pro-
files with small dimensions, easy cutting of non-hardened
nails, screws and steel profiles with small dimensions

TC plunge cut saw
blade, metal

Stainless steel, screws
and nails, epoxy resin,
fibreglass-reinforced
plastics, fibreglass, plas-
terboard, porous concrete

Fast, deep plunge cuts in severely abrasive materials or
metal;
example: Fast cutting of kitchen front covers, easy cutting
through hardened screws, nails and stainless steel.

HCS plunge cut
saw blade for wood

Softwood, dowels, pins,
furniture elements

Fast, deep separating cuts and plunge cuts;
including sawing close to edges in corners and in difficult-
to-reach areas;
example: Deep plunge cut in softwood for installing a vent-
ilation grille

Fitting/changing the application tool

Remove the application tool if one has already been fitted.
To do so, open the SDS lever

(7)

 all the way. The application

tool/accessory will be ejected.
Position the required application tool (e.g. plunge cut saw
blade

(13)

) on the tool holder

(8)

 so that the depressed

centre is facing downwards (see figure on the graphics page,
text on the application tool should be legible from above).

When doing so, place the application tool/accessory in a po-
sition which is convenient for the job at hand. Twelve posi-
tions offset by 30° are possible for this.
Press the application tool in the required position firmly onto
the clamping jaws of the tool holder until it locks automatic-
ally.

u

Check that the application tool is seated securely.

 Ap-

plication tools that are attached incorrectly or are not se-
curely fixed in place may come loose during operation,
thereby putting you at risk.
