18

 | English

1 609 92A 117 | (7.4.15)

Bosch Power Tools

Dust/Chip Extraction



Dusts from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one’s health. Touching or breathing-in the dusts can cause
allergic reactions and/or lead to respiratory infections of
the user or bystanders.
Certain dusts, such as oak or beech dust, are considered
as carcinogenic, especially in connection with wood-treat-
ment additives (chromate, wood preservative). Materials
containing asbestos may only be worked by specialists.

– As far as possible, use a dust extraction system suitable

for the material.

– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the
materials to be worked.



Prevent dust accumulation at the workplace.

Dusts can

easily ignite.

Connecting the Dust Extraction (see figure A)

For sanding, always connect the dust extraction.

Remove the application tool/accessory when mounting the
dust extraction

17

 (accessory).

If required, assemble the parts of the dust extraction

17

 as

shown in the figure. Position the assembled dust extraction
onto the machine via the tool holder

9

. Turn the dust extrac-

tion in such a manner that the cams of the dust extraction en-
gage into the corresponding recesses on the housing. Fasten
the dust extraction to the machine with the retaining clip

15

as shown in the figure.

Pay attention that the felt ring

14

 is undamaged and faces

tightly against the sanding plate

12

. Replace a damage felt

ring immediately.

Depending on the machine model, place a vacuum hose

18

(accessory) either directly onto the vacuum connection

16

 or

cut off the old hose end, screw the extraction adapter

19

 (ac-

cessory) onto the hose end and insert it directly into the vac-
uum connection

16

. Connect the vacuum hose

18

 with a vac-

uum cleaner (accessory). An overview for the connection of
various vacuum cleaners can be found at the end of these in-
structions.

The vacuum cleaner must be suitable for the material being
worked.

When vacuuming dry dust that is especially detrimental to
health or carcinogenic, use a special vacuum cleaner.

Operation

Starting Operation

Inserting the battery



Use only original Bosch lithium-ion batteries with the
voltage listed on the nameplate of your power tool.

Using other batteries can lead to injuries and pose a fire
hazard.

Note:

Use of batteries not suitable for the machine can lead to

malfunctions of or cause damage to the power tool.

Insert the charged battery pack

5

 from the rear into the base

of the power tool. Press the battery pack completely into the
base until the red stripe can no longer be seen and the battery
pack is securely locked.

Switching On and Off

To

start

 the machine, push the On/Off switch

1

 forward so

that the

“I”

 is indicated on the switch.

To

switch off

 the machine, push the On/Off switch

1

 toward

the rear so that the

“0”

 is indicated on the switch.

To save energy, only switch the power tool on when using it.

The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.

Note:

If the machine should automatically switch off because

of a discharged or overheated battery, make sure to set the
machine’s On/Off switch

1

 to off. Charge the battery and al-

low it to cool down before restarting the machine. Otherwise
the battery can become damaged.

Preselecting the Orbital Stroke Rate

With the thumbwheel for preselection of the orbital stroke
rate

4

, you can preselect the required orbital stroke rate, even

during operation.

The required stroke rate depends on the material and the
working conditions and can be determined through practical
testing.

Working Advice



Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.

There is danger of injury when unintentionally actuating
the On/Off switch.



Wait until the machine has come to a standstill before
placing it down.

Note:

Do not cover off the venting slots

2

 of the machine while

working, as this reduces the working life of the machine.

Operating Principle

Due to the oscillating drive the application tool/accessory
oscillates up to 20 000 times per minute at 2.8 °. This allows
for precise work in narrow spaces.

Work with low and uniform application
pressure, otherwise, the working perfor-
mance will decline and the application tool
can become blocked.

While working, move the machine back and
forth, so that the application tool does not
heat up excessively and become blocked.
