10

GB

*Depending on model: it means special equipment for some models or optional accessories.

2. CLEAN THE HEPA FILTER CAPSULE (REF: ZR0043 01)

Important!
Clean the HEPA filter capsule (18): black foam filter (18a) and HEPA filter (18b) every month.
Also be sure to change the entire filtration system on the appliance (ref. ZR0043 01) every year: the air
inlet filter (16), air inlet filter capsule (17) and the HEPA filter capsule (18).

• Remove the flexible tube (19) from the suction opening (8) -

fig. 2

.

• Open the lid (7) of your vacuum cleaner.
• Remove the dust box (11) from its housing (9) -

fig. 10

.

• Simultaneously press the HEPA filter capsule opening clips (15) -

fig. 14a

.

• Separate the black foam filter (18a) from the HEPA filter (18b) -

fig. 14b

.

2.1 CLEANING THE BLACK FOAM FILTER (18a)
•

Wash the black foam filter under the tap, squeeze it out like a sponge and leave to dry for 24 hours -

fig. 16

.

• Once completely dry, assemble the cassette HEPA filter (18): black foam filter (18a) and HEPA filter

(18b) under the dust box (11) and replace the box in its housing (9) -

fig. 15

.

Attention! The foam filter should only be put back into the appliance when it is completely dry.

2.2 CLEANING THE HEPA FILTER (18b)

Attention! Only use the scraper * (28) on the inner side of the filter, never on the outer face, as this
may cause damage or tearing.

• Turn the HEPA filter (18b) over and tap the dust into a dustbin -

fig. 17

.

• then scrape the filter (inner face of the capsule) using the scraper * (28) under cold or warm water,

then leave the HEPA filter to dry for 24 hours -

fig. 18

.

• Once completely dry, assemble the cassette HEPA filter (18): black foam filter (18a) and HEPA filter

(18b) under the dust box (11) and replace the box in its housing (9) -

fig. 15

.

• Ensure that the HEPA filter is completely dry before you put it back in the appliance.

Attention! Make sure that all the filtration system is properly positioned before turning your
appliance back on.

3.  REPLACING THE FILTRATION SYSTEM (REF. ZR0043 01)

• Remove the flexible tube (19) from the suction opening (8) -

fig. 2

.

• Open the lid (7) of your vacuum cleaner.
• Remove the dust box (11) from its housing (9) -

fig. 10

.

3.1. HEPA FILTER CAPSULE (18)

• Simultaneously press the HEPA filter capsule opening clips (15) -

fig. 14a

.

• Separate the black foam filter (18a) from the HEPA filter (18b) -

fig. 14b

.

• If the HEPA filter capsule (18) (black foam filter (18a) and HEPA filter (18b)) is damaged, discard it -

fig. 19

and replace it with a new HEPA filter capsule (ref. ZR0043 01).

• Assemble the HEPA filter capsule (18): black foam filter (18a) and HEPA filter (18b) under the dust box

(11) and replace the box in its housing (9) -

fig. 15

.

3.2. AIR INLET FILTER (16)

• Remove the air inlet filter (16) -

fig. 20a

.

•

Discard it -

fig. 20b

.

•

Replace it with a new air inlet filter (ref. ZR0043 01) -

fig. 20c

.

3.3. AIR OUTLET FILTER (17a)

• Unclip the air outlet filter capsule (17) by lifting the locking clip (13) -

fig. 21-22

.

• Remove the air outlet filter (17a) and discard it -

fig. 23

.

• Replace a new air outlet filter (ref. ZR0043 01) in the capsule (17b).
• Lock the air outlet filter capsule (17) in its housing by pressing the clip (13), until you hear a click -

fig. 24

.
