14

1. Install the mount.

Make sure the mount used to install the projector onto can
support at least five times the weight of the projector. It requires
a professional to carry out the installation.

2. When installing the projector onto a ceiling mount, make sure

the screws meet the following specifications:
Screw Type: Non self-tapping screw M4 × 10 (diameter: 4 mm,
length: 10 mm), 4 pcs.
Assembly Dimensions: See the figure on the right.

3. Adjust the mount depending on your needs and firmly fix the

screws to complete the installation.

Cautions:
- To avoid the convective heat transfer between the air inlets and air outlets, make sure there are no obstructions within 50 cm of the

air inlets and heat dissipation vents.

- Keep the bottom of the projector 10 cm away from the ceiling when suspending it.
- Damage caused by incorrect installation will void the warranty.

Suspended

C

eiling

I

nstallation

Suspended ceiling installation is one of the installation methods that you hang the projector in an overhead location, for example, on a
high ceiling, through a ceiling mount. A projector supporting suspended ceiling installation has threaded holes on the bottom, you can
install the project on the mount by attaching the screws into the holes.

The installation steps are as follows:

235 mm

87.5 mm

135 mm

38.84 mm
