21

the two knobs, no effect will result on oven operation except only for lamp or fan
when switched on. Electric oven is heated by two resistances: one upper resistance
and one circular resistance; by turning the switch knob (Fig.26A-26B) the resistance
referred to the symbol printed on the knob ring will be switched on but in order to put
it in operation  the thermostat knob has to be turned until the orange light on will
confirm that resistance is in operation. By turning the switch knob on one of the 5
operation mode the lamp will be switched on simultaneously with the related
resistance. Once the temperature and the type of resistance are selected, the
operation of the resistance will be controlled by the thermostat. It is therefore
accepted that during operation the orange light will switch on and off.
To turn off the electric oven set the switch knob to position 0 to prevent the
thermostat from controlling the elements. Setting the thermostat knob to position 0
turns off the elements but it is still possible, using the switch, to turn on the electric
fan and the oven light.

The switch has 5 different fixed positions corresponding to 5 different types of oven
operation:

- the symbol

  indicates that only the oven light is turned on;

- the symbol

   indicates that the circular element (3000W) and the electric

fan have been turned on;

- the symbol

 indicates that the grill element (2500W) and the electric fan

have been turned on;

- the symbol

 indicates that only the grill element (2500W) has been turned

on

- the symbol

 indicates that only the electric fan has been turned on.

When the knob is set to one of these five positions, the oven light is always on, thus
indicating that the oven is being energised.

When  5+0 switch is combined with gas thermostat, resistances are switched off;
only lamps and cooling fan operates. It is possible to use the oven convection fan by
selecting on switch knob one of the following modes:

For operating the oven on Dual Energy ranges, see paragraph for use of gas oven.
Once the gas oven use is finished, switch off all the oven functions by turning the
gas thermostat knob and 5+0 switch knob to position 0 (zero).

                                            Fig 26A                                              Fig 26B

Using the electric oven

   Before using the ovens for the first time:

-

Remove all packaging and accessories from inside the ovens.

-

Heat the ovens to 200°C for

½

 hour to burn off manufacturing residues.

-

The automatic programmer must be set to Manual mode for ordinary cooking.

-

The oven will not function when set in Automatic mode. See page 26.

To use the ovens:
1

  Turn the function selector knob (Fig.27A-27B and Fig.28A-28B) clockwise to the

desired function.
The orange light will illuminate, indicating that the element is on.

                                     2

 Turn the temperature selector knob (Fig.29A-29B and Fig.30 for PRO  T version

                                       only)

clockwise to the desired temperature. The orange light will go out once the

                                       oven has reached temperature and is ready for use. It is normal for this light to go
